Quick Start Guide
GV-3D People Counter V2
Before attempting to connect or operate this product,
3DPCV2-QG-C
please read these instructions carefully and save this manual for future use.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GV-3D People Counter V2 and is the answer not in the manual?

Questions and answers

Related Manuals for GeoVision GV-3D People Counter V2

Summary of Contents for GeoVision GV-3D People Counter V2

  • Page 1 Quick Start Guide GV-3D People Counter V2 Before attempting to connect or operate this product, 3DPCV2-QG-C please read these instructions carefully and save this manual for future use.
  • Page 2 GeoVision. Every effort has been made to ensure that the information in this manual is accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind and assumes no responsibility for errors or omissions. No liability is assumed for incidental or consequential damages arising from the use of the information or products contained herein.

  • Page 3: Table Of Contents

    2.2 Terminal Block......................... 4   3. Connection........................5   4. Wall / Ceiling Mount .......................6   5. Accessing the Web Interface ..................8   5.1 Setting the GV-3D People Counter V2 ................... 9   5.2 Accessing Counting Results ....................12   6. Upgrading the Firmware....................13...

  • Page 4: Introduction

    1. Introduction Welcome to the GV-3D People Counter V2 Quick Start Guide. In the following sections, you will learn about the basic installations and configurations of the GV-3D People Counter V2. For the detailed user’s manual, see GV-3D People Counter V2 User’s Manual.

  • Page 5: Overview

    2. Overview 2.1 Bottom and Rear Views Name Function Lens Captures people’s image. Ethernet Port A plug for PoE (IEEE 802.3af). Default Button Resets all configurations to factory default settings. The connectors for the sensor input, alarm output and GPS receiver, Terminal Block see 1.3.3 Auxiliary Device Connectors.

  • Page 6: Terminal Block

    2.2 Terminal Block The 8-pin terminal block, located on the rear panel, provides interfaces for connecting a digital input, a relay output and a GV-GPS Receiver. PIN Assignment Pin Function Digital Input Ground UART RX for GV-GPS Receiver UART TX for GV-GPS Receiver DC 5V Out for GV-GPS Receiver...

  • Page 7: Connection

    1. Plug a standard network cable or PoE to provide power supply and Internet connection. 2. Insert a micro SD card. Note: GV-3D People Counter V2 only supports PoE. You may purchase GV-PA191 PoE adapter to connect to your router. See 1.2 Optional Accessories.

  • Page 8: Wall / Ceiling Mount

    4. Wall / Ceiling Mount You can use the Wall / Ceiling Mount Kit to mount GV-3D People Counter V2 on a desired location. Wall Mount Ceiling Mount 1. Remove the device’s outer case.
  • Page 9 2. Secure the desired mounting kit to the designated position with 2 screws. 3. Reassemble the outer case. 4. Put the installation sticker to the wall with the arrow pointing up. 5. Drill 2 holes according to the sticker and insert the 2 screw anchors to the 2 holes. 6.

  • Page 10: Accessing The Web Interface

    5. Accessing the Web Interface Once the GV-3D People Counter V2 is connected to the network, you can view counting data by using its built-in Web interface, GV-Web Report Lite. When the device is connected to a network with a DHCP server, it will be automatically assigned with a dynamic IP address. To look up this IP address, use GV-IP Device Utility desceribed in Chapter 4 GV-IP Device Utility in GV-3D People Counter User’s Manual.

  • Page 11: Setting The Gv-3D People Counter V2

    5.1 Setting the GV-3D People Counter V2 To set the GV-3D People Counter V2, click the Setup tab on the top. The Setup page appears. [Detection Mode] Choose the desired detection mode from People Counting or Dwell Time.  People Counting: Counting and recording the number of people entering and leaving a designated area based on the directions set.
  • Page 12  For Dwell Time, a timer is set on every person entering the designated area, which only stops and records the dwell time upon the person leaving the area.  Live View: Click to see the black and white live image of the detection area captured by the infrared sensor of the device.
  • Page 13  Detail: Click the button to see an illustration of the detectable range and the dimensions of the detection area based on the height you specified. For details, see 3.2 Setting the GV-3D People Counter V2 in the GV-3D People Counter V2 User’s Manual.

  • Page 14: Accessing Counting Results

    In. 2. When detection mode is set as Dwell Time, Log and Query functions are not supported. For details, see 3.2 Setting the GV-3D People Counter V2 in the GV-3D People Counter V2 User’s Manual.

  • Page 15: Upgrading The Firmware

    6. Upgrading the Firmware We will periodically release the updated firmware on the website. You can update firmware by using GV-Web Report Lite. Download the latest firmware to your computer. Log onto the GV-Web Report Lite and click Setup on the upper right. Select the FW tab.
