Connector Connector Name
Type
DVI
Output 1–8
OPT1–OPT2
Control ETHERNET
USB IN-OUT
www.novastar.tech
MCTRL R5 LED Display Controller User Manual
Description
1440×900@(24/25/30/48/50/60/72/75/85/100/120)Hz
1536×1536@(24/25/30/48/50/60/72/75/85/100)Hz
1600×1200@(24/25/30/48/50/60/72/75/85/100/120)Hz
1920×1080@(24/25/30/48/50/60/72/75/85/100/120)Hz
1920×1200@(24/25/30/48/50/60/72/75/85/100)Hz
2048×640@(24/25/30/48/50/60/72/75/85/100/120)Hz
2048×1152@(24/25/30/48/50/60/72/75/85/100)Hz
2304×1152@(24/25/30/48/50/60/72/75/85/100)Hz
2560×816@(24/25/30/48/50/60/72/75/85/100/120)Hz
2560×1600@(24/25/30/48/50/60)Hz
3840×1080@(24/25/30/48/50/60)Hz

Support HDCP 1.4.

Do NOT support interlaced signal input.
1x DL-DVI input connector

Maximum resolution: 3840×1080@60Hz

Minimum resolution: 800×600@24Hz

Custom resolutions supported
Maximum width: 3840 (3840×1080@60Hz)
Maximum height: 3840 (800×3840@60Hz)

Supported standard resolutions:
1024×768@(24/25/30/48/50/60/72/75/85/100/120)Hz
1280×720@(24/25/30/48/50/60/72/75/85/100/120)Hz
1280×1024@(24/25/30/48/50/60/72/75/85/100/120)Hz
1366×768@(24/25/30/48/50/60/72/75/85/100/120)Hz
1440×900@(24/25/30/48/50/60/72/75/85/100/120)Hz
1536×1536@(24/25/30/48/50/60/72/75/85/100)Hz
1600×1200@(24/25/30/48/50/60/72/75/85/100/120)Hz
1920×1080@(24/25/30/48/50/60/72/75/85/100/120)Hz
1920×1200@(24/25/30/48/50/60/72/75/85/100)Hz
2048×640@(24/25/30/48/50/60/72/75/85/100/120)Hz
2048×1152@(24/25/30/48/50/60/72/75/85/100)Hz
2304×1152@(24/25/30/48/50/60/72/75/85/100)Hz
2560×816@(24/25/30/48/50/60/72/75/85/100/120)Hz
2560×1600@(24/25/30/48/50/60)Hz
3840×1080@(24/25/30/48/50/60)Hz

Do NOT support interlaced signal input.
8x RJ45 Gigabit Ethernet ports

Capacity per port up to 650,000 pixels (8bit) or 325,000 pixels (10bit)

Do not support audio output.

Support redundancy between Ethernet ports.
2× 10G optical ports

OPT 1 copies and outputs the data on Ethernet ports 1–8.

OPT 2 is the copy channel of OPT 1.
Connect to the control computer.

IN: 1x type-B USB 2.0, used as the input port to cascade devices or
connect to PC for device debug
