6.6.6 Presettings

Choose Advanced Settings > Presettings to save current settings as a preset. Up to 10 presets can be
saved.

Save: Save current parameters as a preset.

Load: Read back the parameters from a saved preset.

Delete: Delete the parameters saved in a preset.

6.6.7 Input Backup

Set a backup video source for each primary video source. Other input video sources supported by the
controller can be set as backup video sources.
After a backup video source takes effect, the video source selection is irreversible.
Primary Video source
SDI
DVI
HDMI

6.6.8 Factory Reset

Reset the controller parameters to factory settings.

6.6.9 OLED Brightness

Adjust the brightness of the OLED menu screen on the front panel. The brightness range is 4 to 15.

6.6.10 HW Version

Check the hardware version of the controller. If a new version is released, you can connect the controller to a
PC to update the firmware programs in NovaLCT V5.2.0 or later.
Communication Settings
Set the communication mode and network parameters of the MCTRL R5.
Figure 6-13 Communication mode

Communication mode: Include USB preferred and Local Area Network (LAN) preferred.
The controller connects to PC via USB port and Ethernet port. If USB Preferred is selected, the PC
prefers to communicate with the controller via the USB port, or else via the Ethernet port.
www.novastar.tech
MCTRL R5 LED Display Controller User Manual
Backup Video source
NULL/DVI/HDMI
NULL/SDI/HDMI
NULL/DVI/SDI
15
