Ecb Card Terminals - Danfoss VLT Option Panel Instruction Manual

Input
Conn.
X57
Output
Conn.
X59
Relay
Output
X56
38
Table 6-3. ECB Card Terminals
Term. Function
1 Digital input for safety stop
2 Common
3 Factory use only
4 No function
5 Factory use only
6 Factory use only
7 Factory use only
8 Digital input for remote bypass enable
9 Digital input overrides system to
Bypass Mode ignoring all other inputs
and commands, except for safety stop
on terminal 1.
10 Digital input for remote overload reset
Term. Function
1 Common for binary I/O
2 Common for binary I/O
3 No function
4 No function
5 Digital output indicates panel is in
Drive Mode.
6 Digital output indicates panel is in
Bypass Mode
7 Common for binary I/O
8 Common for binary I/O
Term. Function
1 N.O. contact for running in bypass or
drive
2 N.O. contact for running in bypass or
drive
3 - 12 Factory use only
Type
User supplied dry contact
User supplied dry contact
User supplied dry contact
User supplied dry contact
User supplied dry contact
24 VDC digital output
24 VDC digital output
Relay output for user
Relay output for user.
