Electrical Installation

Wire Size

M
AKE ALL POWER CONNECTIONS WITH MINIMUM
COPPER WIRING FOR INSTALLATIONS IN
• Size wiring to the input current of the drive.
Recommended wire sizes are provided on
the connection drawing inside the cover of
the unit.
• Local codes must be complied with for cable
sizes.
Wire Type Rating
• Use wiring corresponding to the wiring rating
specifications provided.
• The wire rating specifications are located on
the tightening torque and wire rating label
inside the cover of the option panel (see
Figure 3-8).
Terminal Tightening Torques
• Tighten all connections to the torque
specifications provided.
• The torque tightening specifications are
located on the tightening torque and wire
rating label inside the cover of the option
panel (see Figure 3-9.)
Figure 3-9. Sample Tightening Torque and Wire Rating Label
NOTE
75 C
O
RATED
N A .
ORTH MERICA
Field Conn.
Tightening Torque lb-in (N-m)
25 (2.8) / 25 (2.8)
L1, L2, L3 / GND
25 (2.8) / 25 (2.8)
1T1, 1T2, 1T3 / GND
25 (2.8) / 25 (2.8)
2T1, 2T2, 2T3 / GND
7 (0.8)
TB1

Input Line Connection

R ,
UN INPUT POWER MOTOR WIRING AND CONTROL WIRING IN THREE
SEPARATE METALLIC CONDUITS OR RACEWAYS FOR HIGH FREQUENCY
. F
NOISE ISOLATION AILURE TO ISOLATE POWER
CONTROL WIRING COULD RESULT IN LESS THAN OPTIMUM DRIVE AND
ASSOCIATED EQUIPMENT PERFORMANCE
• Connect 3-phase AC input power wire to
terminals L1, L2, and L3. See the connection
drawing inside the cover of the unit.
• Depending on the configuration of the
equipment, input power may be connected to
a circuit breaker or input disconnect.
• Torque terminals in accordance with the
information provided on the connection
diagram inside the cover of the unit.
• Use with Isolated Input Source. Many
utility power systems are referenced to earth
ground. Although not as common, the input
power may be an isolated source. All drives
may be used with an isolated input source
as well as with ground reference power
lines.
Temperature & Type Rating
Use 75 °C Copper Cond.
Use 75 °C Copper Cond.
Use 75 °C Copper Cond.
Use 60 °C Copper Cond.
NOTE
,
MOTOR AND
.
19
