CREO SL: DIAGNOSTICS & TROUBLESHOOTING, MOTOR NOT FOUND
MOTOR NOT FOUND
• SYMPTOM
BIKE BOOTS, BATTERY STARTS AND PROVIDES 12V TO THE TCU
•
• MOTOR PROVIDES NO CAN SIGNAL TO TCU
LIKELY ROOT CAUSE
•
IN MOST CASES, THE MOTOR CABLE-CONNECTION IS INTERRUPTED
•
• REQUIRED ACTION
CHECK AND REPLACE AFFECTED PART
•
CHECK CABLE CONNECTION BATTERY-MOTOR
•
• CHECK CORROSION ON CABLES AND PLUGS
CLEAN CONTACTS
•
RE-BOOT BIKE
•
