Summary of Contents for Specialized STUMPJUMPER FSR 26
-
Page 3: Table Of Contents
COMPONENT TORQUE SETTINGS ........15 FRAME SCHEMATIC .............16 FRAME PIVOT SPECIFICATIONS ...........17 SETUP DATA ................18 Please note all instructions are subject to change for improvement without notice. Please visit www.specialized.com for periodic tech updates. Feedback: techdocs@specialized.com OM0366 - Rev.B, July 2011... -
Page 4: Introduction
Frames or parts under high stress may fail, causing you to lose control or fall. Because of the risk involved, Specialized recommends that you conduct a thorough inspection before each ride. If you miss a jump, ditch your bike in mid crash, dump or launch your bike without you on it, inspect yourself for injury, then carefully inspect your bicycle for damage. -
Page 5: Service And Modifications
Your bicycle has been engineered and tested with specific components and parts. Because of the great variety in these items, it is impossible for Specialized to test and approve of all possible combinations. Modifying the frame, fork, or any of the components may make your bike unsafe. -
Page 6: Fork Setup Information
3. Specialized fork with low position crown 1.5” lower bearing (part # S092500001) „ NOTE: Specialized high crown forks are not compatible with frames with low position bearing. Low bearing head tube 1 1/8” - 1.5” (standard) 1.5” to 1 1/8” Adapter Part #: 2001-9010 1.5”... -
Page 7: Seatpost Setup Information
SEATPOST SETUP INFORMATION SEATPOST MINIMUM INSERTION: To prevent damage to the frame, it’s important to have a minimum amount of seatpost in the seat tube. Carbon frames: Small / Medium - 70mm insertion Large / X-Large - 100mm insertion Aluminum frames: If you cannot see the seatpost tube through the seat tube hole, your seatpost is too far extended. -
Page 8: Frame Features
12. Replaceable Hanger 13. Internal Cable Routing FRAME LINKAGE ASSEMBLY Specialized recommends following a specific order when assembling the rear triangle pivot locations of FSR suspension bike models (see illustration above). 1. Main pivot (#5) 2. Main link pivot (#8) 3. -
Page 9: Frame Geometry
FRAME GEOMETRY 1. Top Tube Length 4. Seat Tube Angle 7. Standover Height 10. Reach 2. Chainstay Length 5. Head Tube Angle 8. Head Tube Length 3. BB Height 6. Wheelbase 9. Stack TT length is the Horizontal Measurement from the center-line of the HT at the top of the HT to the center-line of the projected seat tube. -
Page 10: Stumpjumper Fsr 26
STUMPJUMPER FSR 26” SMALL MEDIUM LARGE X-LARGE 21.89” 23.11” 24.29” 25.28” 16.54” 16.54” 16.54” 16.54” 13.31” 13.31” 13.31” 13.31” 74.5° 74.5° 74.5° 74.5° 68.0° 68.0° 68.0° 68.0° 1090 42.91” 1123 44.21” 1155 45.47” 1181 46.50” 29.33” 29.29” 29.61” 29.96” 4.33”... -
Page 11: Stumpjumper Fsr Carbon 29
STUMPJUMPER FSR CARBON 29 SMALL MEDIUM LARGE X-LARGE 22.32” 23.46” 24.49” 25.51” 17.72” 17.72” 17.72” 17.72” 13.31” 13.31” 13.31” 13.31” 74.5° 74.5° 74.5° 74.5° 69.0° 69.0° 69.0° 69.0° 1117 43.98” 1147 45.16” 1175 46.26” 1203 47.36” 29.53” 29.17” 29.53” 30.08” 3.54”... -
Page 12: Shock Setup
STEP 3: ADJUSTING COMPRESSION Refer to the chart to set the compression damping (blue knob). Specialized / Fox Brain Fade: Stumpjumper Brain Fade controls the Trail Tune inertia valve damping. The blue knob adjusts Trail Tune damping from firm (clockwise) to soft (counter-clockwise) and does... - Page 13 Backing off from full firm can help with tracking in loose terrain conditions while riding off camber sections or climbing. The soft setting can also help during lengthy downhill or rugged conditions where the rider may want the suspension active at all times. Fox RP23: Two positions, Climbing Mode (1 setting) or Open Mode (3 settings).
-
Page 14: Stumpjumper Fsr Air Charts
STUMPJUMPER FSR AIR CHARTS LEGEND Rebound: Counter-clockwise clicks Climbing/Asphalt from full firm Compression: Counter-clockwise clicks Smooth hardpack from full slow Trail riding Fox RP23 Fox Triad Downhill/Technical Fox RP2 COMPRESSION REBOUND BRAIN RP23 TRIAD BRAIN RP23 TRIAD RIDER WEIGHT TERRAIN (KG) (41) (45) -
Page 15: Down Tube Cable Guide Installation
Roval 142+ compatible wheels, please refer to the Roval Hub Compatibility Guide (CG0327), available at www.specialized.com. ACCESSORIES Specialized offers a chainguide that attaches to the DMD front derailleur mount on „ full suspension models and certain hardtail models. The chainguide is designed for single chainring setups up front and regular gears in back, to keep the chain on the chainring. -
Page 16: Carbon Frame Instructions
Bicycle components such as a handlebar, handlebar stem, seatpost, saddle, brakes, must be mutually compatible with each other, as well as the frame and the intended use. Any doubt regarding compatibility should be discussed with your local Specialized Authorized Dealer. -
Page 17: Bottom Bracket
Do not ride if your bicycle shows any of these signs. After any crash, and before you ride any further, take your bicycle to a Specialized Authorized Dealer for a complete inspection. -
Page 18: Frame Schematic
FRAME SCHEMATIC NOTE - Bearing and Bolt Kits are available only through your Specialized Authorized Dealer. To retain your warranty and for your safety, all maintenance should be performed by your local Specialized dealer. -
Page 19: Frame Pivot Specifications
FRAME PIVOT SPECIFICATIONS NOTE: All pivot bolt threads require blue threadlocker. -
Page 20: Setup Data
SETUP DATA DATE RIDER WEIGHT FORK PSI FORK REBOUND DAMPING (# of clicks from full slow) FORK COMPRESSION DAMPING (# of clicks from full firm) SHOCK PSI SHOCK REBOUND DAMPING (# of clicks from full slow) SHOCK COMPRESSION DAMPING (# of clicks from full firm) - Page 24 SPECIALIZED BICYCLE COMPONENTS 15130 Concord Circle, Morgan Hill, CA 95037 (408) 779-6229 www.specialized.com...
