- Page 1 OWNER’S MANUAL...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction... Fork Compatibility... Frame Features... Frame Geometry... Shock Setup... Optional Derailleur Guard Installation... Carbon Frame Instructions... Schematic and Specifications... Warranty... -
Page 4: Introduction
Frames or parts under high stress may fail, causing you to lose control or fall. Because of the risk involved, Specialized recommends that you conduct a thorough inspection before each ride. If you miss a jump, ditch your bike in mid crash, dump or launch your bike without you on it, inspect yourself for injury, then carefully inspect your bicycle for damage. - Page 5 Specialized does not warrant the bicycle frame or components for such activities, and expressly disclaims all warranties, including the warranty of fitness for particular purpose and merchantability.
-
Page 6: Fork Setup Information
Your bicycle has been engineered and tested with specific components and parts. Because of the great variety in these items, it is impossible for Specialized to test and approve of all possible combinations. Modifying the frame, fork, or any of the components may make your bike unsafe. -
Page 7: Frame Features
EPIC / ERA FRAME FEATURES . Main Frame . Seatstay . Chainstay -Link . Main Pivot 6. Dropout (Horst) Pivot -Link at Seatstay Pivot -Link at Frame Pivot 9. Lower Shock Eyelet 0. Upper Shock Eyelet . Shock . Replaceable Derailleur Hanger... -
Page 8: Frame Geometry
EPIC / ERA FRAME GEOMETRY S-Works Epic Carbon Geometry Men’s Small *Top Tube Length 4mm (.8“) **Standover Hgt 76mm (0.00”) Head Tube Length 4mm (4.88”) Head Tube Angle 70.° Seat Tube Angle 74° BB Height mm (.0”) Wheelbase 08mm (4.6”) Chainstay Length 47mm (6.8”) - Page 9 EPIC FRAME GEOMETRY...
-
Page 10: Shock Setup
EPIC / ERA REAR SHOCK SETUP 1. Set sag: • See the attached air chart for starting pressure. Use a high-pressure shock pump to add air. • Turn the Brain Fade knob () counter-clockwise to allow the shock to sag more easily. •... -
Page 11: Derailleur Guard Installation
DERAILLEUR GUARD INSTALLATION The Specialized Derailleur guard is available separately through your local Specialized dealer. The guard works with solid or Q/R axle types and is compatible with all Mountain bike models using the 00-006 Enduro/Demo derailleur hanger. Guard Part #: 9896-400... -
Page 12: Seat Post
Specialized recommends the application of carbon assembly compound between the seat tube and post to increase friction. Recommended compounds can be found at www.tacx.com. See your authorized Specialized retailer if you have any questions. -
Page 13: Bottom Bracket And Headset Installation/Removal
WARNING! Do not pull down on downtube derailleur cables to pre-stress the cables. This can cause damage to the cable guides. Your Specialized frame does not require any Bottom Bracket or Head Tube pre-installation preparation. All surfaces are already prepared from the factory, with the exception of greasing the bottom bracket threads and head set cups. -
Page 14: Product Overview
Schematic #15 Carbon Shock Bracket Dropout Dropouts Shock Link All alloy spacers: Small diameter of spacer facing bearing BB Shell... - Page 15 NOTE: Bearing and Bolt Kits are available only through your local Specialized dealer. To retain your warranty and for your safety, all maintenance should be performed by your local Specialized dealer. Part # Qty. Part Description BB Pivot Bearing Dropout Pivot Bearing...
-
Page 16: Warranty
ADDITIONAL CONDITIONS This Limited Warranty is made only to the original owner of this new Specialized bicycle or frameset purchased from an authorized Specialized dealer, and it shall remain in force only as long as the original owner retains ownership of the Specialized bicycle. This Limited Warranty is not transferable. In order to exercise your rights under this limited warranty, the bicycle or frameset must be presented to an authorized Specialized dealer, together with a receipt, bill of sale or other appropriate written proof of purchase which identifies the bicycle or frameset by serial number. - Page 17 USEFUL PRODUCT LIFE CYCLE Every Specialized bicycle and frameset has a useful product life cycle. The length of that useful product life cycle will vary with the construction and materials of the bicycle or frameset, the maintenance and care the bicycle or frameset receives over its useful product life cycle, and the type and amount of use the bicycle or frameset is subject to. Uses in competitive events, trick riding, ramp riding, jumping, aggressive riding, riding on severe terrain, riding in severe climates, riding with heavy loads, commercial activities and other types of non-standard use can dramatically shorten the useful product life cycle of a Specialized bicycle or frameset.
- Page 18 SPECIALIZED BICYCLE COMPONENTS 0 Concord Circle, Morgan Hill, CA 907 15130 Concord Circle Morgan Hill, CA 95037 www.specialized.com © 2008 Specialized Bicycles PN# W2080309 Please note all instructions are subject to change for improvement without notice. (408) 779-69 Rev., April 007...
