CREO SL: DIAGNOSTICS & TROUBLESHOOTING, BATTERY NOT FOUND
BATTERY NOT FOUND
SYMPTOM
•
BIKE BOOTS, BATTERY STARTS AND PROVIDES 12V TO THE TCU
•
THERE IS NO CAN COMMUNICATION BETWEEN THE BATTERY PACK AND THE TCU
•
• LIKELY ROOT CAUSES
FAULTY/DIRTY/BAD CONNECTIONS
•
WATER INGRESS IN CABLES & CONNECTIONS
•
• BROKEN CAN TRANSCEIVER (ON BATTERY SIDE)
BMS MODULE DEFECT
•
REQUIRED ACTIONS
•
• CHECK CABLE CONNECTIONS
CHECK FOR CORROSION ON CABLES AND PLUGS
•
CLEAN CONTACTS AND RE-BOOT BIKE
•
• CHECK WITH RANGE EXTENDER CONNECTED IF WIRING HARNESS IS STILL OKAY
