- Page 1 OWNER’S MANUAL TURBO S TURBO X TURBO FLR TURBO...
-
Page 3: Table Of Contents
4. SPECIALIZED TURBO COMPONENTS ........ -
Page 4: Introduction
Specialized Bicycle Owner’s Manual. Please read the instruction on how to use the bicycle technology as well as the instructions relating to the electric assist technology before you use this bicycle. If you do not have a copy of the Specialized Bicycle Owner’s Manual, you can download it for free at www.specialized.com, go to your nearest Authorized Specialized Retailer, or contact Specialized... -
Page 5: Model Differentiation
This Owner’s Manual covers several Turbo models and model years, from 2014 to present. 2013 Turbo S models have the 1st generation computer display (see illustration below). If your Turbo has this display, please refer to the 2013 Turbo S Owner’s Manual. -
Page 6: Quick Start
If the diode on the charger flashes red, an error has occurred during charging. If this is the case, please remove the charger from the power socket immediately and contact your Authorized Specialized Dealer right away. Do not ride your bicycle until this error has been corrected. -
Page 7: Removing / Installing The Battery
Removing / installing the battery Checking the battery diagnostic STARTUP DIAGNOSTIC MOTOR OK 2 SEC OFF! BATTERY OK LIGHT OK REMOTE OK OFF! ANY LED BLINK x2: • Connection failed • Component can’t be found CLICK! WARNING! Before you ride the bicycle, please familiarize yourself with the behavior and operation of the bicycle in a quiet, safe place. -
Page 8: Specialized Turbo Components
4. SPECIALIZED TURBO COMPONENTS 1. Top tube 12. Rear light 23. Screen / joystick (page 34. Charging socket and magnetic rubber plug (page 14,page 2. Down tube 13. Reflector 24. Handlebar with grip 14. Kickstand 25. Shifter 3. Seat tube 35. -
Page 9: Safety Information
Check the tires and rims. Scan them for any damage, cracks or deformations, as well as embedded particles, e.g. shards of glass or sharp stones. If you should find any cuts, rips or holes in the tires, please refrain from riding. First have your bicycle checked over by your Authorized Specialized Dealer. -
Page 10: User Interface
WARNING! Before you switch the system on, ensure that the magnetic rubber plug is attached to the frame. The contacts below it are live with electricity when the system is switched on. WARNING! If you are unsure of whether your bicycle is in a sound technical condition, take it to your Authorized Specialized Dealer to be checked instead of riding it. - Page 11 SET UNIT (km/h or mph) SET UNIT (km/h or mph) (Models with reed switch) (Models without reed switch) 3 sec HOLD 10 sec HOLD 3 sec 0 sec 10 sec km/h (kilometers) mph (miles) km/h (kilometers) mph (miles) Set unit: Press the „...
-
Page 12: Screen Modes
D. Screen modes ECO % +/- ADJUST Set ECO level: When the speed setting is in „ ECO mode, the ECO # will be displayed. • If nothing is done for 3 seconds, the ECO 3 sec # disappears. DO NOTHING •... -
Page 13: Motor/Support
„ On request, the bicycle support can be reduced to a maximum of 25 km/h (15.5 mph) by your Authorized Specialized Dealer (does not apply to all models and/or all markets). In this case, the vehicle is classified as a Pedelec and is subject to other rights and obligations. Among other things, helmet and insurance requirements may be affected depending on national laws. -
Page 14: Error Codes Displayed
If you receive such an error, please restart the system. If the error message continues to be shown, please contact your Authorized Specialized Dealer for further instructions. Depending on the type of error message, the system may be switched off automatically. It is possible to continue riding with this system switched off without support from the motor, at any time. -
Page 15: Charger
WARNING! If the red LED flashes during the charging process, a charging error has occurred. If this is the case, please remove the charger from the socket immediately and contact your Authorized Specialized Dealer to identify the fault. In this case, the bicycle, battery and the charger may no longer be used. -
Page 16: Cleaning
Please only use the Specialized charger supplied with the bicycle or other chargers approved by Specialized. Check the charger before every use for possible damage to the charger itself, the cable or the plug: Never use a charger which you suspect is damaged or know is broken. -
Page 17: Battery Information System
12.F. If the bicycle works normally despite a flashing LED, you are still able to use your bicycle with support. However, you should find your Authorized Specialized Dealer in order to find the cause of the flashing LED. B. Charge level display Once the diagnosis is complete (fig.10), the charge level of the battery is permanently displayed during your ride (fig.11). -
Page 18: Removal / Installation
If you want to ship the battery or your bicycle, please consult your Authorized Specialized Dealer first as well as the transport company in order to find out which precautionary measures you have to take. The consultation of an expert for hazardous materials prior to transport is absolutely required. -
Page 19: Disposal
When removing/installing the seatpost, be sure to unplug/plug the two wires that connect the backlight to the electrical system. There is no order or polarity to the two wires. Specialized recommends applying a piece of tape to the wires to stick the wires to the seat tube when the wires are disconnected, to avoid the possibility of the wires falling into the seat tube and out of reach. -
Page 20: Dealing With A Flat Tire / Removing A Wheel
Modern technology is highly efficient but also sensitive. You should service your bicycle on a regular basis. This requires expert knowledge and tools. Allow your Authorized Specialized Dealer to do this type of work on your bicycle. You can get more information about your bicycle’s parts as well as cleaning and maintenance in the instruction manual provided by your manufacturer or on the... -
Page 21: Lubrication
Please ensure that the electric bicycle cannot be used by any third persons without your consent. Please only ride your electric bicycle again when your Authorized Specialized Dealer has checked your electric bicycle. -
Page 22: Legal Regulations
Assisted Cycle (EPAC - DIN EN 15194) with support up to a maximum of 25 km/h (15.5 mph). On request, the pedal assist support can be increased to 45 km/h (28 mph) or decreased to 25 km/h (15.5 pmh) by your Authorized Specialized Dealer (depending on the model; certain models are DIN EN 15194 or L1e only). -
Page 23: Other Legal Regulations
July, 2012, require the use of a bicycle helmet. L1e S-Pedelecs have to be insured as a low-performance moped. Any changes to the L1e S-Pedelec/Pedelec not approved by Specialized, which could lead to a change in the motor performance and/ or the possible top speed, have the following effects: •... -
Page 24: L1E S-Pedelecs And Cycle Paths
These regulations also apply to you if you are within the scope of the European Union. Differing regulations may apply in other countries, including other European nations in isolated cases. Please inform yourself about the applicable legislation before using your L1e S-Pedelec. D. -
Page 25: Replacing Parts On Your L1E S-Pedelec
Standard ETRTO Max. Load Model Standard ETRTO Max. Load Size Size (kg) Size Size (kg) Specialized Borough XC Sport 45-622 700x45 Continental E.Contact 37-622 37-622 700x37 Specialized Borough Sport 45-622 700x45 Continental E.Contact 42-622 42-622 700x42 Specialized Borough Armadillo 45-622... -
Page 26: Torque Specs
35 in-lbf (4 Nm) Brake levers 22 in-lbf (2.5 Nm) 22. TECHNICAL INFORMATION Weight of Specialized Turbo: 49-50 lb (22.3-22.7 kg) Capacity (SBC-B01): 11 Ah / 396Wh WEIGHT Maximum permitted weight: 295 lb (134 kg) Capacity (SBC-B02): 13 Ah / 468Wh... -
Page 27: Turbo Diagnosis Decision Tree
23. TURBO DIAGNOSIS DECISION TREE Specialized recommends that any diagnosis be performed by your Authorized Specialized Dealer. Component(s) (motor, light, remote, rear brake) not found/not functioning (Any light blinks twice). MOTOR BATTERY LIGHT REMOTE Refer to Owner’s Manual - Turn battery off... -
Page 28: Eg - Declaration Of Conformity
Product designation: Specialized Turbo Type designation: Turbo S, Turbo X, Turbo FLR or Turbo Year of construction: 2015 The conformity with all applicable directives from the guideline: Machines (2006/42/EG). The machine also conforms to all the directives in the guideline: Electromagnetic compatibility (2004/108/EG). -
Page 29: Dealer Service Schedule
25. DEALER SERVICE SCHEDULE 1st Inspection: 2nd Inspection: 3rd Inspection: After approx. 200 kilometers (120 miles) After approx. 1000 kilometers (600 miles) After approx. 2000 kilometers (1200 miles) Work done: Work done: Work done: ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________... -
Page 30: Handover Documentation
HANDOVER DOCUMENTATION... - Page 32 SPECIALIZED BICYCLE COMPONENTS 15130 Concord Circle, Morgan Hill, CA 95037 (408) 779-6229...
