CREO SL: DIAGNOSTICS & TROUBLESHOOTING, MOTOR ERROR
MOTOR ERROR
SYMPTOM
•
BIKE BOOTS, BATTERY STARTS AND PROVIDES 12V TO THE TCU
•
MOTOR PROVIDES A CAN SIGNAL TO TCU STATING "I AM IN ERROR MODE"
•
LIKELY ROOT CAUSE
•
CAN BE TRIGGERED BY AN ISSUE WITH THE SPEED SENSOR OR WHEEL MAGNET
•
CAN BE A MOTOR-RELATED ISSUES, SUCH AS A FAULTY TORQUE SENSOR OR
•
DYSFUNCTIONAL INTERNAL SPEED SENSOR
REQUIRED ACTION
•
• CHECK/REPLACE SPEED SENSOR SYSTEM
• IS THE WHEEL MAGNET CLEAN AND INTACT?
• IS THE SPEED SENSOR CABLE INTACT AND INSTALLED PROPERLY?
• IS THE SIGNAL RECEIVER IN CHAINSTAY POSITIONED CORRECTLY?
IS THE SPEED SENSOR CABLE PROPERLY CONNECTED TO MOTOR?
•
ARE THE CONNECTORS INTACT AT MOTOR?
•
CHECK AND/OR REPLACE AFFECTED PART
•
• IF SPEED SENSOR SYSTEM IS OKAY, TEST ANOTHER MOTOR
