Summary of Contents for Specialized FSR
- Page 1 OWNER’S MANUAL...
-
Page 3: Table Of Contents
Headset installation / removal ............. . 12 SPECIALIZED BICYCLE COMPONENTS Please note all instructions are subject to change for improvement without notice. -
Page 4: Introduction
INTRODUCTION Congratulations on your purchase and welcome to the finest line of suspension bikes available! About Off Road, Stunt, Downhill and Freeriding This manual is designed to be used in conjunction with the Bicycle Owner’s Manual and owner’s manuals supplied by the manufacturer of the front and rear suspension components. -
Page 5: Bike Setup Specifications
For additional information regarding Roval 142+ compatible wheels, please refer to the Roval Hub Compatibility Guide (CG0327) at www.specialized.com. Accessories Specialized offers replacement chainstay protectors for most FSR models, available through your „ Specialized authorized dealer. Page 3 of 12... -
Page 6: Pf30 Bottom Bracket Assembly
PF30 BOTTOM BRACKET ASSEMBLY This design allows for the installation of Specialized OSBB carbon cranks, or the installation of different adapters to fit a variety of crank offerings. Installing PF30 and PF30DH Bottom Bracket Cups Specialized frames with 73 x 46mm (PF30) and 83 x 46mm (PF30DH) bottom bracket specifications feature a bottom bracket shell with a 46mm inner diameter, and accept 42x30x7mm BB30 bearings pressed into proprietary Specialized press-in cups. - Page 7 INSTALLING THE BOTTOM BRACKET REDUCERS (Shimano and SRAM) SHIMANO CRANKS (PART #S120400003) Shimano reducers require no spacers or wave washer. Refer to „ the Shimano crank instruction guide for additional installation information. SRAM GXP CRANKS (PART #S120400004) Reducer adapter cups SRAM GXP cranks require a wave washer and spacers on the „...
-
Page 8: Fork Length Specifications
FORK LENGTH SPECIFICATIONS WARNING! Specialized frames are compatible ONLY with forks that have a specific maximum amount of travel (see table below). Use of different styled forks or forks with longer travel may result in catastrophic failure of the frame which may result in serious personal injury or death. -
Page 9: Frame Specifications
FRAME SPECIFICATIONS DESCRIPTION EPIC CAMBER MYKA HEADSET 1 1/8” upper / 1.5” lower 1 1/8” upper / 1.5” lower 1 1/8” upper / 1 1/8” lower SEATPOST DIAMETER 30.9mm 30.9mm 30.9mm SEAT COLLAR (CARBON) 34.9mm 34.9mm SEAT COLLAR (ALLOY) 34.9mm 34.9mm 34.9mm FRONT DERAILLEUR CLAMP... -
Page 10: Autosag Air Shock Setup
AUTOSAG AIR SHOCK SETUP All Epic, Camber, Stumpjumper and Safire models are equipped with AUTOSAG, a unique new feature designed to simplify and speed up the adjustment of air pressure. The AUTOSAG feature automatically determines the correct amount of sag, and eliminates the need to refer to an air chart to determine the correct pressure based on rider weight. -
Page 11: Rockshox Ario Air Shock Setup
ROCKSHOX ARIO AIR SHOCK SETUP Step 1: Adjusting sag Myka FSR sag: 7.5-9.5mm (20-25%) RIDER WEIGHT ARIO DB AIR (KG) NOTE: See the chart for starting air pressures, or refer to the Sag-O-Tron decal on the side of the seat tube and link to (41) dial in the sag. -
Page 12: Coil Shock Setup
COIL SHOCK SETUP Step 1: Adjusting sag Proper sag should be achieved with one turn of preload on the spring. More then two turns of preload will require a higher spring rate or not enough „ sag will require a softer spring rate. See spring rate chart for additional information or refer to the shock manual. „... -
Page 13: Shock Settings
SHOCK SETTINGS COMPRESSION BRAIN SHOCK COMPRESSION EPIC SJ 26 / 29 SJ 26 / 29 CAMBER CAMBER MYKA FSR (Counter- SAFIRE CAMBER SJ 26 / 29 clockwise clicks from full firm) SAFIRE ENDURO TERRAIN BRAIN (Race tune) BRAIN (Trail Tune) -
Page 14: Carbon Frame Instructions
Seatpost Refer to your seatpost owner’s manual prior to installation. Specialized FSR frames have a 30.9mm seatpost diameter and require that the seatpost have a tolerance of 30.78mm to 30.95mm. Do not grease the inside surface of the carbon seat tube! Certain Specialized carbon frames use a quick-release seatpost binder. - Page 16 SPECIALIZED BICYCLE COMPONENTS 15130 Concord Circle, Morgan Hill, CA 95037 (408) 779-6229...
