Board Dimensions
The Weather Carrier Board measures 2.65" x 2.30" (67.31mm x 58.42mm) and has four mounting holes that fit a
standard 4-40 screw.

Hardware Assembly

Now that we are familiar with the hardware and sensors on the Weather Carrier Board, it's time to assemble it with
your chosen MicroMod Processor and get it connected to your computer.
Inserting your Processor
With the M.2 MicroMod connector, connecting your processor board is a breeze. Simply match up the key on your
processor's beveled edge connector to the key on the M.2 connector. At a 45° angle, insert the processor board to
the M.2 connector. The processor board will stick up at an angle as seen here:
SPI_CS
SPI_SCK
SPI_COPI
SPI_CIPO
RTC_3V
SD_CS
SPI_SCK
SPI_COPI
Out/Peripheral In signal.
SPI_CIPO
In/Peripheral Out signal.
RTC_3V
µSD Chip Select.
SPI clock signal.
SPI Controller
SPI Controller
3V output for backup
battery charging.
