Location Requirements

Note: The cabinet is equipped with leg levelers to ease level cabinet
installation. It should be located on a flat surface for proper cabinet
alignment and door operation.

Exhaust Requirements

If you intend to connect the cabinet to the optional Exhaust Connection Kit,
first examine the location to ensure that it accommodates the cabinet's
exhaust duct. The area directly above the cabinet's exhaust port should be
clear of structural elements, water and utility lines, or other fixed
obstructions. There should be enough clearance to accommodate a 5-inch
diameter duct. For further information about the cabinet's exhaust system
requirements, please refer to Appendix D: Accessories.

Electrical Requirements

The evidence drying cabinet models have the following electrical
requirements:
Model #
33900-00
33900-01
Note: An outlet with a circuit breaker rated at 10 amps for 115 volt
models (5 amps for 230 volt models) should be located as close as possible
to the right rear side of the cabinet. Power cords supplied with the
Evidence Drying cabinet are 3 meters (10 feet) long.
Product Service 1-800-522-7658
Chapter 2: Prerequisites
Table 2-1
Requirements
115 VAC, 60 Hz, 6 Amps
230 VAC, 50/60 Hz, 3 Amps
