Do not discard the carton or packing material for the cabinet until all of the
components have been checked, installed and tested.
The cabinet is secured to the pallet using four (4) bolts. To remove the
cabinet, remove four (4) bolts from underneath top skid boards that are
holding the cabinet to the skid. You do not need to save these bolts and
washers. In the clear plastic bag inside the cabinet, are four (4) leg levelers.
Screw these into the holes the bolts came out of before removing the cabinet
from the pallet.
The cabinet is now ready to be removed from the pallet.
After removing the cabinet from the pallet, carefully remove plastic wrapping
around the cabinet, and open the cabinet door. Locate the two transport
brackets attached to the face of the cabinet liner. Using a #2 Phillips
screwdriver, remove the screws securing the brackets, discard the brackets,
and reinstall the screws.
Preparing the Evidence Drying Cabinet for
Operation
After the evidence drying cabinet has been removed from its pallet and
positioned in its final location, you must:
1. Remove the tie and/or tape securing the door, and the filters on top of
the unit.
2. Ensure that the transport brackets have been removed from the front
of the cabinet liner.
Note: The following are located in a box in the cabinet:
 User's Manual
 UV Security Lock Key(s) (model #s 34000-00, -04 only)
 Power Cord
 Product Registration Card
If you did not receive one or more of the components listed for the
cabinet, or if any of the components are damaged, contact Labconco
Corporation immediately for further instructions.
3. Using a step ladder, remove the tape and/or packaging material
around the top of the unit.
4. Plug the power cord into the back of the cabinet, and then into an
appropriate outlet. Install the Key into the UV Security lock on the
upper panel on those models equipped with a UV light.
