Serial Data Interface

The serial asynchronous interface allows connection to external serial devices through RS232 interface. It
is shared between user data and unit's command/status information. The following options of serial port
parameters are supported:
Baud rate
Flow control
Data bits
Stop bits
Parity

Power Interface

The power interface allows connection to an unregulated DC power source. The DC power source (third party
or user supplied) must provide DC power of 4.2V±5% DC.

Power Consumption

Power consumption of the Beacon OEM receiver at receiving mode is 1400 mW (refer to Table below for
details).
Operating Mode / Description
Maximum for Rx Full Operation Mode
Sleep Mode
Standby Mode, ordered by SLEEP input pin

Antenna

The Beacon receiver should be used with 283.5 - 325 kHz antenna with following parameters:
• LNA Gain P30 dB
• LNA Noise Figure 1.5 dB
8

GENERAL DESCRIPTION

Parameter
115200, 57600, 38400, 19200, 14400, 9600, 4800, 2400,
1200 bauds per second
None, Hardware
8
1, 2
None
Serial port parameters
Options
Consumption
1400 mW
300mW
500 mW
