Tahoe Entertainment Unit
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
13
6
Attach 1 x left slide rail (G) to panel [6] and secure with 2 x small screw (E).
Attach 1 x right slide rail (G) to panel [9] and secure with 2 x small screw (E).
mocka.co.nz | mocka.com.au
9
G
E
E
G
E
14
NOTE: If the doors are
uneven or there is a gap in
the middle, loosen or tighten
the screw on the hinge until
19
Attach panel [19] a n d [ 2 0 ] to panel as shown. Secure with 16 x screws (L).
Tighten with a screwdriver.
K
20
17
8
