Tahoe Entertainment Unit
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
1
Drawer x 2
A
A
Insert 8 x bolt (A) into panel [5]. Tighten with a screwdriver.
mocka.co.nz | mocka.com.au
5
A
5
A
A
2
B
A
B C
C
A
Insert 4 x locking nut (B) into panels [1] .Attach 4 x bolt (A) into panel [1]. Attach
4 x dowel (C) to panel [1] and secure with [5]. Tighten with a screwdriver.
A
A
1
B
B
C
C
5
2
