Mocka Tahoe Entertainment Unit Assembly Instructions Manual page 6

Tahoe Entertainment Unit
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
9
D
M
D
D
L
D
D
Attach panel [8] to panel [2] with 10 x long screws (D). Attach centre support 2 x
shekf plug (N) to panel [2]. Attach 2 x long screw (M) to centre support (M) as
shown.
mocka.co.nz | mocka.com.au
M
D
8
M
D
L
D
D
D
2
10
K
L
L L
L L
K
K
20
Attach 4x hinge (K) to panel [19] and [20] and secure with 8 x small screw (L).
L
L
L
L
K
K
19
6
