Mocka Tahoe Assembly Instructions Manual

Tahoe Entertainment Unit
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
C
A B
bolt locking dowel
x21 nut x 21 x24
F
G H
long L + R L + R
screw x 5 slide rail slide rail
x 2
K L
screw
hinge
x24 screw x2
x 4
Hardware Supplied
Phillips & Flathead screwdrivers and hammer required
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
mocka.co.nz | mocka.com.au
D E
small
long screw
x18 screw x8
I J
nut
long
x 4
screw x 4
x 2
O
M N
cover
long shelf
plug x2 x 4
WARNING: Any furniture that is not anchored to a wall has the potential to tip
W
over in certain circumstances, i.e. if a child attempts to climb up on the furniture
or in the event of an earthquake. Accordingly, we recommend that all furniture
is anchored to a wall. We supply a free safety wall anchor with all furniture sold
and we recommend these are used to prevent your product tipping. The fixing
device provided should fit most wall types, but please note that different wall
materials may require different fixing devices from those supplied.
safety long
strap screw
x1 x1
X Y
wall screw
anchor x1
x1
Z
washer
x1
*We recommend using a Flathead screwdriver to tighten all locking nuts 100% before first use.
Please clear any loose wood from the locking nut holes before inserting the nut to ensure it locks 100%.
1
