- Page 1 HMD914 SERIES PORTABLE MAGNETIC DRILL OPERATOR’S MANUAL COVERS DRILL PART NUMBERS 0914104, 0914202, 0914204, 0914302, 0914304, 0914402 & 0914404 FOR USE WITH HOUGEN ROTABROACH CUTTERS ® ® OM9140913 Printed in U.S.A.
-
Page 2: Safety First
Portable Magnetic Drill . Your model is designed to ® produce superior holes quickly and efficiently. Through constant innovation and development, Hougen is committed to provide you with hole producing tools and products to help you be more productive. Before attempting to operate your new Portable Magnetic Drill, please read all instructions first. These include the Operator’s Manual and Warning Label on the unit itself. -
Page 3: Important Safety Instructions
Important Safety Instructions WARNING: Read and understand all instructions. Failure to follow all instructions listed below, may result in electrical shock, fire and/or serious personal injury. Work Area Use safety equipment. Always wear eye production. Dust mask, non-skid safety shoes, hard hat, or hearing protection Keep your work area clean and well lit. -
Page 4: Safety Switch Indicator Light
Arbor and cutter should never be used as a hand- hold. Keep hands and clothing away from all moving parts. Do not use Hougen Cutters where ejected slug might cause injury (slug ejected at end of cut). For any questions please contact Hougen Manufacturing’s Also, adhere to all operating instructions. -
Page 5: Commercial / Industrial Limited Warranty
No other expressed warranty is given or authorized. Hougen Manufacturing, Inc. disclaims any implied warranty of MERCHANTABILITY or FITNESS for any period beyond the expressed warranty and shall not be liable for incidental or consequential damages. - Page 6 OPERATING INSTRUCTIONS Always remember that the magnet’s holding power is directly related to the workpiece thickness and surface condition. Since magnetic attraction diminishes with thinner material or rough surfaces, mechanical clamping of drill unit to workpiece should be used when cutting thin material (3/8"...
- Page 7 Bass Barb Fitting. Make sure nut is seated properly in coolant bracket Brass Fitting (vinyl tube to coolant inducer) 07080 not included in 05060 kit. 0914104 HMD914 MAGNET BASE DRILL (115V Standard Base) Item Part No. Description Magnet / Switch Assembly 05969...
- Page 8 0914202 HMD914 Magnet Base Drill (230V Standard Base) 0914204 HMD914 Magnet Base Drill (230V Swivel Base) 0914402 HMD914 Magnet Base Drill (230V Standard Base, No Plug) 0914404 HMD914 Magnet Base Drill (230V Swivel Base, No Plug) Item Part No. Description Magnet / Switch Assembly 07066 230v, 0914202 &...
- Page 9 0914302 HMD914 Magnet Base Drill (230V Standard Base, Type I Plug) 0914304 HMD914 Magnet Base Drill (230V Swivel Base, Type I Plug) Item Part No. Description Magnet / Switch Assembly 07066 230v standard base, 0914302 Magnet / Switch Assembly 05984 230v swivel base, 0914304 Arbor / Front Support Brkt Assembly 07074...
- Page 10 Swivel Base Magnet Assembly 05969 Swivel Magnet Assembly 115V (includes 1-12) 0914104 05970 Magnet/Safety Switch Assembly 115V, 0914104 ( includes a-d) 05971 Magnet Assembly 115V, 0914104 05652 Ball Switch Assembly 05975 Plunger 05670 Retain. Ring 05984 Swivel Magnet Assembly 230V (includes 1-12)
- Page 11 Bolt 3/8-24 X 3 40392 Flat Washer 40391 Lock Washer 40234 Thrust Washer 40398 Retaining Ring 05935 Arbor Assembly with Coolant Inducer 0914104, 0914204, 0914304 & 0914404 07075 Arbor Body Assembly Item Qty. Part No. Description 07077 Arbor Body 10517...
-
Page 12: Housing Assembly Breakdown
MOTOR/SLIDE ASSEMBLY BREAKDOWN 05976 Motor / Slide Assembly 0914104 Item Part No. Description 05983 Motor Assembly (115V) includes 1a-1d 40258 Motor Cord 40445 Strain Relief 02411 Strain Relief 90019 16-14GA.Female Terminal 05977 Slide Assembly 05978 Spacer 02428 Rack Gear 01121... - Page 13 115V CONTROL PANEL ASSEMBLY BREAKDOWN 115V Control Panel Assembly 05188 115V Control Panel 0914104 Item Part No. Description 07011 Faceplate 90571 Power Cord Assembly (115 volt) 02548 Stand Off 3/16 X 9/16 01334 Motor ON Switch 04881 L.E.D Buld 04877 Wire Harness L.E.D...
- Page 14 230V CONTROL PANEL ASSEMBLY BREAKDOWN 230V Control Panel Assemblies 07067 230V Control Panel 0914202, 204, 402 & 404 Item Part No. Description 07011 Faceplate 07299 Power Cord Assembly 05942 230V Control Panel 0914302 & 0914304 05829 Faceplate 04498 Power Cord Assembly Shared Components 02548 Stand Off 3/16 X 9/16...
-
Page 15: Motor Parts Diagram
MOTOR PARTS DIAGRAM 40441 40382 40260 40384 40284 (115v) 40449 40445 01088 (230v) 40258 40383 40450 40271 40286 (115v) 40267 40349 40298 40265 40289 05834 (230v) 40285 40269 40266 40267 40287 40273 40262 40276 40262 40292 40263 40279 50035 40290 40275 40261 (115v) 40264...
