Summary of Contents for Hougen HMD927 Series
- Page 1 HMD927 SERIES POWER FEED MAGNETIC DRILL Covers Drill Part Number: 0927102 0927104 OM9270717EF Printed in U.S.A. 3/2019...
- Page 2 Portable Magnetic Drill. Your model is designed to produce superior holes quickly and ® efficiently. Through constant innovation and development, Hougen is committed to provide you with hole producing tools and products to help you be more productive. Before attempting to operate your new Portable Magnetic Drill, please read all instructions first. These include the Operator’s Manual and Warning Label on the unit itself.
- Page 3 WARNING Cutters are sharp. Wear To prevent electric Do not stare at Always wear eye The slug is ejected at gloves when installing shock, do not use operating light. protection while using the end of the cut. Do or removing cutter from power tools near wet cutting tools, or in the not aim cutter or arbor...
-
Page 4: Additional Safety Instructions
fire and/or serious personal injury. h) Keep handles and grasping surfaces, clean and Do not use Hougen Cutters where ejected slug might cause Important Safety Instructions - Continued injury (slug ejected at end of cut). Also, adhere to all free from oil and grease. -
Page 5: Safety Switch Indicator Light
RPM recommendations are based on using your HMD927 drill with Hougen "12,000-Series" H.S.S. Cutters. The RPM’s do not represent optimum speeds for any given cutter diameter and application. For more information refer to Hougen’s Speed & Feed Calculator located on Hougen.com, or call 1-800-426-7818 for Technical Support. - Page 6 START switch. 9. Feed Hougen Cutter slowly into workpiece. Only after cutting path is established to a depth of about 1/16" can full force be applied to feed handles. 10. Ease up on feed pressure as cutter starts breaking through.
-
Page 7: Coolant Bottle Assembly
Set Screws go here 4. Insert proper pilot in shank end of Hougen Cutter. 5. Insert Hougen Cutter until flat on cutter shank is aligned with set Pilot screw holes and is exactly perpendicular to axis of set screw holes. - Page 8 HMD927 MAG BASE DRILL #51 - Coolant Arbor Assembly Coolant Bottle Assembly (see page 7) Motor Assembly (see page 12) Motor/Slide 07870 FRONT SUPPORT BRACKET ASSEMBLY 07076 COOLANT INDUCER ASM 40301 WASHER-THRUST 1-3/8 X 2-1/16 X Assembly 1/32 07869 ARBOR ASM 40398 RING-RETAINING 1-9/16"...
- Page 9 HMD927 Breakdown HMD927 Breakdown Item Part # Description Item Part # Description 40594 Bolt - Hex HD 3/8-24 x 3" 08134 Motor / Slide Assy. 40391 Lock Washer - Helical 3/8 07950 Coolant Bottle Assy. 40392 Washer - Flat 3/8 Type A 10559 SCR BHC #10-32 x 1-1/4 LG 07831...
- Page 10 CONTROL PANEL BREAKDOWN & WIRING 08138 Panel Assembly 2 & 3 Item Part # Description 08139 Faceplate Power Feed Magnetic Drill 4 & 5 01335 Switch - Motor Off 01228 Cover - Switch Red 01334 Switch - Motor On 02409 Cover - Switch Green 05336 Boot - Mini, Toggle Switch...
- Page 11 MOTOR SLIDE ASSEMBLY BREAKDOWN 08134 Motor & Slide Assembly Item Part # Description 08135 Motor Complete Assembly 40038 SCR BHC #10-32 x 5/8 LG 08062 Bottle Support 10560 Lock Washer Ext. #10 07955 Slide - Dovetail 08001 Rack - Gear 05185 Pin - Dowel 90028...
-
Page 12: Motor Parts Diagram
MOTOR PARTS DIAGRAM 08135 Motor Assembly Item Part # Description Item Part # Description 05209 SCR SHC #10-32 X 1-3/4 17610 Washer - Flat 8mm 50038 Washer - Lock Helical #10 07903 Needle Bearing 07860 Retaining Ring 07969 Gear Box Cover 40274 Bearing 25mm x 47mm x 12mm 08070... -
Page 13: Maintenance
MAINTENANCE In order to minimize wear on moving parts and to insure smoother operation and longer life for your magnetic drill, the following maintenance should be done periodically, based on use. 1. Regularly tighten all fasteners and replace all worn parts. 2. - Page 14 ARBOR & FRONT SUPPORT BRACKET REMOVAL AND INSTALLATION Coolant Arbor Removal 1. Loosen arbor support bracket bolts. 2. Remove screw in coolant inducer. Rotate arbor until arbor screw is in line with hole. 3. Loosen set screw holding arbor onto motor output shaft. 4.
-
Page 15: Hints For Smoother Operation
HINTS FOR SMOOTHER OPERATION 1. Keep the inside of Hougen Cutter clear of chips. Chips will interfere with cutting to maximum depth, maybe impede the free oil flow and can cause cutter breakage. #1 cause of cutter 2. Keep work, machine, arbor and Hougen Cutter free of chips and dirt. -
Page 16: Commercial / Industrial Limited Warranty
This warranty is void if the item has been damaged by accident or unreasonable use, neglect, improper service, or other causes not arising out of defects in material or workmanship. No other expressed warranty is given or authorized. Hougen Manufacturing, Inc.
