- Page 1 HMD914 SERIES PORTABLE MAGNETIC DRILLS COVERS DRILL PART NUMBERS 0914104, 0914202, 0914204, 0914302, 0914304, 0914402 & 0914404 0914304, 0914402 & 0914404 FOR USE WITH “12,000-SERIES” HOUGEN FOR USE WITH “12,000-SERIES” HOUGEN CUTTERS CUTTERS ® ® ®...
-
Page 2: Safety First
Manual and Warning Label on the unit itself. With proper use, care, and maintenance, your model will provide you with years of effective hole drilling performance. Once again, thank you for selecting our product and welcome to Hougen. The HMD914 is offered in many versions. Refer to the Serial/Part number Label on your housing to direct you to the correct breakdown. -
Page 3: Important Safety Instructions
Important Safety Instructions WARNING: WARNING: Read and understand all instructions. Failure to follow all instructions listed below, may result in electrical shock, fire and/or serious personal injury. ���� ���� ���� ���� � ��� ������ ���������� ������ ���� ��� ����������� ���� �����... - Page 4 ������ �� ��� ��� ������ ������� ����� ������� ���� ����� ����� ������ ����� ������� �� ��� �� ����� ����� ������ �� ��� ��������� ������������� �� ��� ����� For any questions please contact Hougen Manufacturing’s ������� ��� ������� ���� ��� ������� ���� ���������� Technical Service at (810) 635-7111.
- Page 5 (at its option) without charge any items returned. This warranty is void if the item has been damaged by accident or unreasonable use, neglect, improper service, or other causes not arising out of defects in material or workman- ship. No other expressed warranty is given or authorized. Hougen Manufacturing, Inc. disclaims any implied warranty of MERCHANTABILIT...
-
Page 6: Operating Instructions
Operating Instructions Always remember that the magnet’s holding power is directly related to the workpiece thickness and surface condition. Since magnetic attraction diminishes with thinner material or rough surfaces, mechanical clamping of drill unit to work- piece should be used when cutting thin material (3/8” or less) or material with uneven surfaces. Note: Always form a loose knot in the power cord close to the molded plug. -
Page 7: Drill Maintenance
Installing the HOUGEN Cutter 1. Disconnect power source. 2. Lay drill on its side with feed wheel up to be sure arbor clears table if unit is in normal operating position. 3. Turn feed handles until cutter mounting set screws are exposed and then completely remove the set screws. - Page 8 SAFETY CHAIN USE The safety chain should be used to prevent the drill unit from falling in the event of a power failure or if the magnet breaks loose from the work surface. The safety chain should be attached to the drill by running it between the Front Support Bracket and the Drll Housing and then continue around the material and/or work surface.
- Page 9 0914104 HMD914 Magnet Base Drill (115v Swivel Base) Item Part No. Description Magnet / Switch Assembly 05969 115v (0914104) Arbor / Front Support Brkt Assembly 05935 115v (0914104) Drill Housing Assembly 07337 Control Panel Assembly 05188 Motor / Slide Assembly (115 volt) 05976 05979 Coolant Inducer Bracket...
- Page 10 0914202 HMD914 Magnet Base Drill (230v Standard Base) 0914204 HMD914 Magnet Base Drill (230v Swivel Base) 0914402 HMD914 Magnet Base Drill (230v Standard Base, No Plug) 0914404 HMD914 Magnet Base Drill (230v Swivel Base, No Plug) Item Part No. Description Magnet / Switch Assembly 07066 230v, 0914202 &...
- Page 11 0914302 HMD914 Magnet Base Drill (230v Standard Base, Type I Plug) 0914304 HMD914 Magnet Base Drill (230v Swivel Base, Type I Plug) Item Part No. Description Magnet / Switch Assembly 07066 230v standard base, 0914302 Magnet / Switch Assembly 05984 230v swivel base, 0914304 Arbor / Front Support Brkt Assembly 07074...
- Page 12 Swivel Base Magnet Assembly 05969 Swivel Magnet Assembly 115v (includes 1-12) � 0914104 05970 Magnet/Safety Switch Assembly �� 115v, 0914104 ( includes a-d) � 05971 Magnet Assembly 115v, 0914104 05652 Ball Switch Assembly 05975 Plunger � 05670 Retain. Ring �� ��...
-
Page 13: Individual Components
07074 Arbor Assembly with Coolant Inducer 0914202, 0914302 & 0914402 07075 Arbor Body Assembly Item Qty. Part No. Description 07077 Arbor Body 10517 Retaining Ring 07079 Spring Seat 05049 Spring 40223 Ejection Collar 40312 Roll Pin 40222 Set Screws 7/16-14 X .305 40256 Set Screw 5/16-18 X .38 40344... - Page 14 05935 Arbor Assembly with Coolant Inducer 0914104, 0914204, 0914304 & 0914404 07075 Arbor Body Assembly Item Qty. Part No. Description 07077 Arbor Body 10517 Retaining Ring 07079 Spring Seat 05049 Spring 40223 Ejection Collar 40312 Roll Pin 40222 Set Screws 7/16-14 X .305 40256 Set Screw 5/16-18 X .38 40344...
- Page 15 115 volt Control Panel Assembly 05188 115v Control Panel 0914104 Item Part No. Description 07011 Faceplate 90571 Power Cord Assembly (115 volt) 02548 Stand Off 3/16 X 9/16 01334 Motor ON Switch 04881 L.E.D Buld 04877 Wire Harness L.E.D 05826 Circuit Board (120 volt) 04614...
- Page 16 230 volt Control Panel Assemblies 07067 230v Control Panel 0914202, 204, 402 & 404 Item Part No. Description 07011 Faceplate 07299 Power Cord Assembly 05942 230v Control Panel 0914302 & 0914304 05829 Faceplate 04498 Power Cord Assembly Shared Components 02548 Stand Off 3/16 X 9/16 01334 Motor ON Switch...
- Page 17 07337 Drill Housing Assembly Use with the 115 volt machines Item Part No. Description 07336 Drill Housing (includes 1-1e) 07038 Safety Label 07035 115 volt Label 40237 Set Screw 1/4-28 X 1/2 Serial Number Label 40231 Bronze Bushing 40229 Feed Gear 40254 Feed Hub Assembly 05839...
- Page 18 05976 Motor / Slide Assembly 0914104 Item Part No. Description 05983 Motor Assembly (115 volt) includes 1a-1d 40258 Motor Cord 40445 Strain Relief 02411 Strain Relief 90019 16-14GA.Female Terminal 05977 Slide Assembly 05978 Spacer 02428 Rack Gear 01121 Screw SHC 1/4-28 X 1-1/4 90028 Lock Washer 40038...
-
Page 19: Motor Parts List
40441 40382 40260 40384 40449 40284 (115v) 40445 01088 (230v) 40258 40383 40450 40271 40286 (115v) 40267 40349 40298 40265 40289 05834 (230v) 40285 40269 40266 40267 40287 40273 40262 40276 40262 40292 40263 40279 50035 40290 40275 40261 (115v) 40264 01087 (230v) 40274...
