- Page 1 OPERATOR’S MANUAL HMD934 SERIES PORTABLE MAGNETIC DRILL Covers Drill Covers Drill Part Numbers: Part Numbers: 0934102 0934202 0934302 OM9340717EF Printed in U.S.A.
-
Page 2: Table Of Contents
Portable Magnetic Drill. Your model is designed to produce superior holes quickly ® and effi ciently. Through constant innovation and development, Hougen is committed to provide you with hole producing tools and products to help you be more productive. Before attempting to operate your new Portable Magnetic Drill, please read all instructions fi rst. These include the Operator’s Manual and Warning Label on the unit itself. -
Page 3: Safety Instructions
WARNING Cutters are sharp. Wear To prevent electric Do not stare at Always wear eye The slug is ejected at gloves when installing shock, do not use operating light. protection while using the end of the cut. Do or removing cutter from power tools near wet cutting tools, or in the not aim cutter or arbor... -
Page 4: Safety Chain Instructions
Keep hands and clothing away from all moving parts. may result in electrical shock, fire and/or serious personal injury. Do not use Hougen Cutters where ejected slug might cause h) Keep handles and grasping surfaces, clean and Important Safety Instructions - Continued injury (slug ejected at end of cut). -
Page 5: Operating Instructions
40126 - Coolant Btl. Assembly * Complete and mail the Product Registration *(sometimes packed separately) Card NOW. It is important that Hougen Mfg., Inc. have a record of product ownership. 5. Lift the unit out of the shipping case. Contents of Tool Box 6. -
Page 6: Feed & Glide Post Adjustment
FEED ADJUSTMENT Drag Screw must be adjusted against the Feed Rod so that main housing moves freely up and down the feed rods when feed wheel is turned, so that main housing stays in position on feed rod when wheel is released. Drag Screw GLIDE POST ADJUSTMENT Adjustment is made with magnet on and glide... -
Page 7: Ejector Rod Adjustment
EJECTOR ROD ADJUSTMENT In addition to providing a positive method to insure that a To adjust the ejector rod: slug is not retracted with the cutter, the ejector rod serves as a conduit for the cutting fl uid and as a centering guide for Place the Mag Drill on a steel plate and turn the positioning the Mag Drill on the workpiece. -
Page 8: Installing Hougen Cutters
Pilot 4. Insert Hougen Cutter on ejector rod. 5. Insert Hougen Cutter until flat on cutter shank is aligned with set screw holes and is exactly perpendicular to axis of set screw holes. 6. Insert set screws and tighten. Check to be certain that cutter is secure. -
Page 9: Operation Of Coolant Bottle
OPERATION OF CUTTING FLUID RESERVOIR When everything is ready to go (Magnet ON and Impactors seated), open the Adjustment Needle to provide a generous flow of cutting fluid until a puddle approximately the diameter of the cutter being used is developed on the workpiece. Once this initial supply of cutting fluid is established on the workpiece, adjust the flow to a steady drip. -
Page 10: Control Panel Breakdown
CONTROL PANEL BREAKDOWN & WIRING 3 & 4 08577 Panel Assembly 120V 08585 Panel Assembly 230V 2 & 5 Item Part # Description 07011 Faceplate 01335 Switch - Motor Off 01334 Switch - Motor On 02409 Seal - Green 01228 Seal - Red 01226 Guard Switch... -
Page 11: Motor Breakdown
MOTOR PARTS 08579 Motor Assembly 120V 08586 Motor Assembly 230V Item Part # Description Item Part # Description 41048 SCR-SHC #10-32 x 1-1/2 07911 Assembly Gears #2 & #3 50038 Washer - Lock Helical #10 08278 Gear Box Cover 07860 Retaining Ring 24093 Washer - Spring... -
Page 14: Hmd934 Parts Breakdown
HMD934 Part # Description Part # Description 40126 Bottle Assembly 40130 Safety Switch Assy 04909 Bracket-Safety Switch 40126 Cap (Must buy Bottle Assy) 10983 40123 Hold Down Fitting Shield-Safety Switch 40058 Washer 10971 SCR-SHC 1/4-20 x 1/2 90497 SCR-SS 1/4-20 x 3/8 BR 40121 Bottle 08550... - Page 15 HMD934 PARTS BREAKDOWN Part # Description Part # Description 40010 Driven Gear 16 Teeth 40076 Dowel Pin 1/4 40020 Thrust Washer 40003 Housing Spindle Bearing 40038 SHCS 10-32 x 5/8 40005 Lower Bearing Cap Assy 10560 Washer #10 40078 SCR-SHC 1/4-20 x 1-1/2 40037 Upper Retaining Ring 40077...
-
Page 16: Commercial / Industrial Limited Warranty
No other expressed warranty is given or authorized. Hougen Manufacturing, Inc. disclaims any implied warranty of MERCHANTABILITY or FITNESS for any period beyond the expressed warranty and shall not be liable for incidental or consequential damages.
