- Page 1 OPERATOR’S MANUAL HMD900 PORTABLE MAGNETIC DRILL Covers Drill Covers Drill Part Numbers: Part Numbers: 0900101 OM900 Printed in U.S.A. 10/2023...
-
Page 2: Specifications
Portable Magnetic Drill. Your model is designed to produce superior holes quickly and ® efficiently. Through constant innovation and development, Hougen is committed to provide you with hole producing tools and products to help you be more productive. Before attempting to operate your new Portable Magnetic Drill, please read all instructions first. These include the Operator’s Manual and Warning Label on the unit itself. -
Page 3: Electrical Safety
WARNING Cutters are sharp. Wear To prevent electric Do not stare at Always wear eye The slug is ejected at gloves when installing shock, do not use operating light. protection while using the end of the cut. Do or removing cutter from power tools near wet cutting tools, or in the not aim cutter or arbor... -
Page 4: Important Safety Instructions
fire and/or serious personal injury. h) Keep handles and grasping surfaces, clean and Do not use Hougen Cutters where ejected slug might cause Important Safety Instructions - Continued free from oil and grease. Slippery handles and injury (slug ejected at end of cut). - Page 5 4. Insert proper pilot in shank end of Hougen Cutter. 5. Insert Hougen Cutter until flat on cutter shank is aligned with set screw holes and is exactly perpendicular to axis of set screw holes.
- Page 6 HMD900 115V MAG BASE DRILL Motor/Slide Assembly (see page 7) Motor Assembly (see page 9) Control Panel Assembly (see page 8)
- Page 7 HMD900 Breakdown 09370 Magnet Assembly Item Part # Description Item Part # Description 09381 Motor Slide Assembly - 3 speed 10971 SCR-SHC 1/4-20 x 1/2 09400 Brass Gib - Right Hand 04909 Bracket - Safety Switch 09399 Brass Gib - Left Hand...
-
Page 8: Safety Switch
CONTROL PANEL BREAKDOWN & WIRING Safety Switch to Motor 09391 Panel Assembly Item Part # Description 09386 Faceplate 09394 ON/OFF Switch 04614 Rocker Switch, Double Pole 90571 Power Cord Assembly 17032 SCR-BHC 6-32 x 1/2 01835 Nut- Hex Nylon 09388 Capacitor Assembly 09387 Rectifier Assembly... - Page 9 MOTOR PARTS DIAGRAM 9 10 09134 Motor Assembly Item Part # Description Item Part # Description 08234 SCR SHC #10-32 X 1-5/8 LG 07857 Gear Box Cover 50038 Washer - Lock Helical #10 17630 Armature 07860 Retaining Ring 07849 SCR SHC #10-32 x 2 LG 40274 Bearing 25mm x 47mm x 12mm 50038...
-
Page 10: Maintenance
MAINTENANCE In order to minimize wear on moving parts and to insure smoother operation and longer life for your magnetic drill, the following maintenance should be done periodically, based on use. 1. Regularly tighten all fasteners and replace all worn parts. 2. -
Page 11: Hints For Smoother Operation
HINTS FOR SMOOTHER OPERATION 1. Keep insides of Hougen Cutter clear of chips. Chips will interfere with cutting to maximum depth and can cause cutter breakage. #1 cause of cutter 2. Keep work, machine, arbor and Hougen Cutter free of chips and dirt. -
Page 12: Commercial / Industrial Limited Warranty
This warranty is void if the item has been damaged by accident or unreasonable use, neglect, improper service, or other causes not arising out of defects in material or workmanship. No other expressed warranty is given or authorized. Hougen Manufacturing, Inc.
