Design and function
Remote control
5.7
Remote control
5.7.1
Foot-operated switch
5.8
Function sequence
5.8.1
Foot-operated switch
Item
Symbol Description
1
2
WELD SPEED
Symbol
I
t
18
Functions
•
Start/stop turntable/tilting table.
•
It is connected to the 3-pole remote control connection socket.
0
Switch for changing the rotational direction of the rollers
•
Workpiece rotates anti-clockwise, when viewed from the driven dolly
•
Workpiece rotates clockwise, when viewed from the driven dolly
Changeover switch, "WELD/RAPID" rotation speed
•
"WELD" position = welding mode with rotation speed set
•
"RAPID" position = positioning, rotary plate with maximum speed regardless of the
set rotation speed. There is no start signal for the welding machine.
I
Meaning
Welding current
Welding process time
Rotating device turns right in a clockwise direction
Rotating device turns left in an anti-clockwise direction
Figure 5-6
t
t
099-010253-EW501
26.11.2010
