4.3.2
Rear view
Item
Symbol Description
1
2
3
4
5
6
7
099-010253-EW501
26.11.2010
Machine description – quick overview
0
Mounting holes
2-pole connection socket, motor connection
3-pole connection socket, foot-operated switch
Mains voltage 115V/230V changeover switch
Earth cable
Machine switch, on/off
Connection socket mains cable
Figure 4-4
CB-006
11
