Design and function
Positioning the workpiece
5.3
Positioning the workpiece
Damage to the machine due to incorrect position of the workpiece!
Workpieces that are not positioned properly damage the machine!
•
Place the workpiece carefully on the rollers without touching other parts of the machine when
doing so!
5.4
Connection for workpiece lead
Electric shock!
In order to avoid injuries, make sure that the cables and hoses are fitted correctly when
connecting and working with the machine.
•
Connect all cables and hoses in such a way as to prevent them being crushed or getting
caught when using the turntable!
•
After installation or conversion, all mechanical and electrical connections must be tested for
correct installation!
Risk of burns due to incorrect connection of the workpiece lead!
Paint, rust and dirt on the connection restrict the power flow and may lead to stray
welding currents.
Stray welding currents may cause fires and injuries!
•
Clean the connections!
•
Fix the workpiece lead securely!
•
Do not use structural parts of the workpiece as a return lead for the welding current!
•
Take care to ensure faultless power connections!
•
Use a rotating earth clamp when connecting the workpiece lead.
14
CAUTION
DANGER
CAUTION
099-010253-EW501
26.11.2010
