5.5
Connecting the machine controls
Item
Symbol Description
1
2
•
Position the machine control on the mounting bolts using the mounting holes.
Mounting process using an example. Procedure is similar for other models as
appropriate.
099-010253-EW501
26.11.2010
0
Mounting holes
Fixing pin
To fasten the machine control
Design and function
Figure 5-3
NOTE
Connecting the machine controls
15
