J5 Usb; J7 Analog/4-20Ma; J8 Watermark - Arduino AKX00034 Product Reference Manual

5.3 J5 USB

Pin Function Type
1 VUSB Power
2 D- Differential USB differential data -
3 D+ Differential USB differential data +
4 ID NC
5 GND Power

5.4 J7 Analog/4-20mA

Pin Function
1,3,5,7 +19V
2 IN1
4 IN2
6 IN3
8 IN4
9 GND
10 +5V
11 A5
12 A1
13 A6
14 A2
15 A7
16 A3
17 A8
18 A4

5.5 J8 Watermark

Pin Function
1 WaterMrk1
2 WaterMrk2
3 WaterMrk3
4 WaterMrk4
5 WaterMrk5
6 WaterMrk6
7 WaterMrk7
8 WaterMrk8
9 WaterMrk9
10 WaterMrk10
11 WaterMrk11
12 WaterMrk12
13 WaterMrk13
14 WaterMrk14
17 / 25
Description
Power Supply Input Note: A board powered only via V USB will not enable most of
the features of the board. Check the power tree in Section 3.8
Unused
Ground
Type Description
Power 4-20mA voltage reference
Analog 4-20mA input 1
Analog 4-20mA input 2
Analog 4-20mA input 3
Analog 4-20mA input 4
Power Ground
Power 5V output for 0-5V analog reference
Analog 0-5V input 5
Analog 0-5V input 1
Analog 0-5V input 6
Analog 0-5V input 2
Analog 0-5V input 7
Analog 0-5V input 3
Analog 0-5V input 8
Analog 0-5V input 4
Type
Analog
Analog
Analog
Analog
Analog
Analog
Analog
Analog
Analog
Analog
Analog
Analog
Analog
Analog
Arduino® Edge Control
Arduino® Edge Control
Description
Watermark input 1
Watermark input 2
Watermark input 3
Watermark input 4
Watermark input 5
Watermark input 6
Watermark input 7
Watermark input 8
Watermark input 9
Watermark input 10
Watermark input 11
Watermark input 12
Watermark input 13
Watermark input 14
Modified: 17/12/2021
