J11 Relay (+/- Vbat); Mechanical Information - Arduino AKX00034 Product Reference Manual

Pin Function
17 GATED_VBAT_PULSE
18 GND

5.8 J11 Relay (+/- VBAT)

Pin Function
1 SOLAR+
2 NC
3 GND
4 RELAY1_P
5 NC
6 RELAY1_N
7 NC
8 RELAY2_P
9 NC
10 RELAY2_N
11 10kGND
12 RELAY3_P
13 NTC
14 RELAY3_N
15 GND
16 RELAY4_P
17 BATTERY+
18 RELAY4_N

6 Mechanical Information

19 / 25
Type
Power
Power
Type Description
Power Solar Panel Positive Terminal
NC Unused
Power Ground
Switch Relay 1 positive
NC Unused
Switch Relay 1 negative
NC Unused
Switch Relay 2 positive
NC Unused
Switch Relay 2 negative
Power Ground via 10k resistor
Switch Relay 3 positive
Analog Negative temperature coefficient (NTC) thermoresistor
Switch Relay 3 negative
Power Ground
Switch Relay 4 positive
Power Battery Positive Terminal
Switch Relay 4 negative
Arduino® Edge Control
Arduino® Edge Control
Description
Gated Positive terminal of battery
Ground
Modified: 17/12/2021
