J9 Latching Out (+/- Vbat); J10 Latching Command (+/- Vbat) - Arduino AKX00034 Product Reference Manual

Pin Function
15 WaterMrk15
16 WaterMrk16
17,18 VCOMMON

5.6 J9 Latching Out (+/- VBAT)

Pin Function
1 PULSE_OUT0_P
2 PULSE_OUT0_N
3 PULSE_OUT1_P
4 PULSE_OUT1_N
5 PULSE_OUT2_P
6 PULSE_OUT2_N
7 PULSE_OUT3_P
8 PULSE_OUT3_N
9 PULSE_OUT4_P
10 PULSE_OUT4_N
11 PULSE_OUT5_P
12 PULSE_OUT5_N
13 PULSE_OUT6_P
14 PULSE_OUT6_N
15 PULSE_OUT7_P
16 PULSE_OUT7_N
17,18 GND

5.7 J10 Latching Command (+/- VBAT)

Pin Function
1 STOBE8_P
2 STOBE8_N
3 STOBE9_P
4 STOBE9_N
5 STOBE10_P
6 STOBE10_N
7 STOBE11_P
8 STOBE11_N
9 STOBE12_N
10 STOBE12_P
11 STOBE13_P
12 STOBE13_N
13 STOBE14_P
14 STOBE14_N
15 STOBE15_P
16 STOBE15_N
18 / 25
Type Description
Analog Watermark input 15
Analog Watermark input 16
Digital Sensor common voltage
Type Description
Digital Latching output 1 positive
Digital Latching output 1 negative
Digital Latching output 2 positive
Digital Latching output 2 negative
Digital Latching output 3 positive
Digital Latching output 3 negative
Digital Latching output 4 positive
Digital Latching output 4 negative
Digital Latching output 5 positive
Digital Latching output 5 negative
Digital Latching output 6 positive
Digital Latching output 6 negative
Digital Latching output 7 positive
Digital Latching output 7 negative
Digital Latching output 8 positive
Digital Latching output 8 negative
Power Ground
Type Description
Digital Latching command 1 positive
Digital Latching command 1 negative
Digital Latching command 2 positive
Digital Latching command 2 negative
Digital Latching command 3 positive
Digital Latching command 3 negative
Digital Latching command 4 positive
Digital Latching command 4 negative
Digital Latching command 5 positive
Digital Latching command 5 negative
Digital Latching command 6 positive
Digital Latching command 6 negative
Digital Latching command 7 positive
Digital Latching command 7 negative
Digital Latching command 8 positive
Digital Latching command 8 negative
Arduino® Edge Control
Arduino® Edge Control
Modified: 17/12/2021
