Processor - Arduino AKX00034 Product Reference Manual

Ref. Description
U11 W25Q16JVZPIQ Flash 16M IC
U7 CD4081BNSR AND gate IC

3.2 Processor

The Main Processor is a Cortex M4F running at up to 64MHz.
10 / 25
Board topolgy back
Ref. Description
Q3 ZXMP4A16GTA MOSFET P-CH 40V 6.4A
U14, 15 MC14067BDWG IC MUX
Arduino® Edge Control
Arduino® Edge Control
Modified: 17/12/2021
