What's Next?
The next series of steps depends on what type of dampening material you are using:
• For PDJ, proceed to "Applying the Pipe Dampening Jacket - PDJ" on page 27 .
• For DMP-1 and DMP-3, proceed to "Installing the First Transducer Mounting Block" on page 28 .
26
o
180 Point
Origin line,
min. 12 in. (30 cm) long
Side View
(on opposite side of pipe)
