4. To find the corresponding point on the opposite side of the pipe (180° away), divide the measured pipe
circumference by 2 and measure this distance along the circumferential line from the zero point. Take the 180°
point measurement from both over the top of the pipe and under the bottom of the pipe (on a horizontal pipe) to
ensure accuracy of the installation. Mark a small scribe line at the 180
5.
Mark another origin line at the 180
Model C-RL Installation Guide
Zero Point
Origin line, min. 12 in. (30 cm) long
o
point at least 12 in. (30 cm) long.
Side View
o
point.
180 deg
and C/2
180 deg
and C/2
