4.
Install the four nuts onto the threaded rods with the convex side of the nut facing the fixture. Hand tighten each
nut evenly as shown below. Do not use a cross-tightening pattern.
10
Zero on Each
Measuring Scales
Mating Half
Top View
Top View
Model C-RL Installation Guide
