Panametrics T17 Installation Manual

Ultrasonic flow transducer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Flow
Model T17
Ultrasonic Flow Transducer
Installation Guide
916-128 C
panametrics.com
August 2021

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T17 and is the answer not in the manual?

Questions and answers

Related Manuals for Panametrics T17

Summary of Contents for Panametrics T17

  • Page 1 Flow Model T17 Ultrasonic Flow Transducer Installation Guide 916-128 C panametrics.com August 2021...
  • Page 3 User’s Manual 916-128C August 2021 panametrics.com Copyright 2021 Baker Hughes company. This material contains one or more registered trademarks of Baker Hughes Company and its subsidiaries in one or more countries. All third-party product and company names are trademarks of their respective...
  • Page 4 [no content intended for this page]...
  • Page 5 If you do, serious injury can result. WARNING! Make sure that power to the auxiliary equipment is turned OFF and locked out before you perform maintenance procedures on the equipment. Model T17 Installation Guide...
  • Page 6 The crossed-out wheeled bin symbol invites you to use those systems. If you need more information on the collection, reuse and recycling systems, please contact your local or regional waste administration. Visit www.bakerhughesds.com/health-safetyand-environment-hse for take-back instructions and more information about this initiative. Model T17 Installation Guide...
  • Page 7 Chapter Model T17 Installation Guide...
  • Page 8 Chapter [no content intended for this page] Model T17 Installation Guide...

  • Page 9: Table Of Contents

    3.1.1 For 3 inch Flanges ..................33 Chapter 4. Inserting T17 Transducers into the Pipe Introduction .
  • Page 10 Contents viii Model T17 Installation Guide...
  • Page 11 Contents Model T17 Installation Guide...
  • Page 12 Contents Model T17 Installation Guide...

  • Page 13: Chapter 1. Introduction

    • A transducer head that consists of piezoelectric elements wired to the BNC connector • A BNC style connector for use in connecting the transducer to the flowmeter The T17 transducer is available in standard lengths of 33 in. (840 mm) to 60 in. (1500 mm) and with either a 180 angled head.

  • Page 14: Certification And Safety Statements

    EN 60079-1:2007 and IEC 60079-1:2007 Ex d IIC. Measures must be taken to ensure a good electrical contact and to prevent the threads from self-loosening. The compression fitting is suitable for temperatures –60°C to 250°C. Model T17 Installation Guide...

  • Page 15: Chapter 2. Installing Pipe Nozzles

    Introduction Before the T17 transducers can be installed into the pipe, you will need to install pipe nozzles. Nozzles may be installed as part of a fabricated spoolpiece, or by using the hot or cold process with a Panametrics Nozzle Installation Kit.
  • Page 16 • Selecting and marking the first nozzle location • Determining and marking the second nozzle location • Installing the first welding boss • Installing the first nozzle • Installing the second welding boss and nozzle • Hot tapping the pipe Model T17 Installation Guide...

  • Page 17: Identifying And Checking The Nozzle Installation Kit Components, Diametrical

    Figure 4: Components in Nozzle Installation Kit Check the marking on the welding boss. The pipe OD and the mounting angle are engraved on the boss as shown below. Pipe O.D. Code for Diametrical Path Mounting Angle Model T17 Installation Guide...

  • Page 18: Selecting And Marking The First Nozzle Location, Diametrical

    We recommend that you install the nozzles on a diameter as near as possible to the horizontal plane (i.e., 3 o’clock and 9 o’clock positions) for horizontal pipe. Note: If you cannot find a proper location, please consult with Panametrics Flow Application engineering. Model T17 Installation Guide...
  • Page 19 At the 3 o’clock position, center punch the pipe to mark the position for the center of the first nozzle. Side View Spray this area with a marking dye product. Using a metal edge, scribe 6” long vertical and a horizontal lines that intersect at the center punch mark. Side View Model T17 Installation Guide...

  • Page 20: Determining And Marking The Second Nozzle Location, Diametrical

    IMPORTANT: Ensure that the sides of the film are cut parallel to each other. • Width: equal to the average outside diameter calculated in Step 2 above. • Length: equal to 4 times the outside diameter of the pipe. Average O.D. 4 x O.D. Model T17 Installation Guide...
  • Page 21 Remove the strip of film and fold it as shown below to determine the position which is diametrically opposite the overlap position when the film is reapplied to the pipe. Overlap Mark Fold to Here Mark the outside of the fold for reference. Mark the Edge Model T17 Installation Guide...
  • Page 22 Center punch this location prior to removing the strip of film. Punch Here Fold Mark Second Edge Side View Remove the film. 10. Scribe 6” long vertical and horizontal lines that intersect at the center-punch mark. Scribe Lines Side View Model T17 Installation Guide...

  • Page 23: Installing The First Welding Boss, Diametrical

    Scribe the oblique center line on the pipe at the prescribed distance from the true center line. The oblique center line should be marked on the side of the true center line that is closer to the second nozzle location. Oblique Center Line True Center Line Side View Model T17 Installation Guide...
  • Page 24 Check the boss alignment, then tack weld the carbon steel boss to the pipe in each of the four grooves between the boss scribe marks. Remove the clamp and check the alignment again. If the boss is misaligned by 0.02 in. (0.5 mm) or more, remove the boss, grind off the welds and reinstall it. Model T17 Installation Guide...

  • Page 25: Installing The First Nozzle, Diametrical

    Slide the nozzle over the threaded rod, and align the contoured end of the nozzle so it matches the pipe arc. Then slide the jig over the threaded rod, fitting the jig into the welding boss. Model T17 Installation Guide...
  • Page 26 0.6 in. (15 mm) in length. Allow the welds to cool for 30 seconds between tacks. Proceed to complete the root pass and subsequent filler passes as required. Allow the welds to cool, then remove the threaded rod, washer, nut, and jig. Model T17 Installation Guide...

  • Page 27: Installing The Second Welding Boss And Nozzle, Diametrical

    Install the second welding boss and nozzle at the required position as described in “Installing the First Welding Boss, Diametrical” on page 11 and “Installing the First Nozzle, Diametrical” on page 13. The completed installation should appear as shown below. NOZZLE 2 PLACES WELDING BOSS 2 PLACES FLOW 45° Model T17 Installation Guide...

  • Page 28: Hot Tapping The Pipe

    • Selecting and marking the first nozzle location • Determining and marking the second nozzle location • Installing the first welding Boss • Installing the first nozzle • Installing the second welding boss and nozzle • Hot tapping the pipe Model T17 Installation Guide...

  • Page 29: Identifying And Checking The Nozzle Installation Kit Components, Non-Diametrical, Mid-Radius

    Figure 5: Components for Nozzle Installation Kit Check the marking on the cylindrical surface of the welding boss. The pipe OD and the mounting angle are engraved on the boss as shown below. Mounting Angle Code for Mid-Radius Model T17 Installation Guide...

  • Page 30: Selecting And Marking The First Nozzle Location, Non-Diametrical, Mid-Radius

    We recommend that you install the nozzles on a chord as near as possible to the horizontal plane for horizontal pipe. Note: If you cannot find a proper location, please consult with Panametrics Flow Application engineering. Model T17 Installation Guide...
  • Page 31     – D 2W CHORD     ---------------- -        -- - –   CHORD   -- for mid-radius     Model T17 Installation Guide...
  • Page 32 Selecting and Marking the First Nozzle Location, Non-Diametrical, Mid-Radius (cont.) --- - --- - ------- -  Nozzle 2nd Nozzle --- - D 2W – ------------------ - CHORD D 2W –       ------------------ -      Model T17 Installation Guide...
  • Page 33 66 in. 66 in. 34.774 in. (883.25 mm) Using the calculated dimension AS/2 in 4, center punch the pipe to mark the position for the center of the first nozzle. Reference Point Center Point of 1st Nozzle Model T17 Installation Guide...

  • Page 34: Determining And Marking The Second Nozzle Location, Non-Diametrical, Mid-Radius

    The nozzles cannot be mounted on the header pipe if they are located, by mistake, at the mirror image to this convention. Model T17 Installation Guide...
  • Page 35 Step 2. Chord – D 2W     ---------------- -      W = 0.375” Chord Location = 0.5 • Length: equal to 3.5 times the outside diameter of the pipe. Model T17 Installation Guide...
  • Page 36   Chord – D 2W     ---------------- -      W = 0.375” Chord Location = 1/2   -- - –   Mark Line 3.5 X D. Model T17 Installation Guide...
  • Page 37 The new position for the center of the second nozzle is now identified as the intersection of the mark line and the second edge of the strip of film. Center punch this location prior to removing the strip of film. Punch Here Mark Line Overlapping Area Second Edge Model T17 Installation Guide...

  • Page 38: Installing The First Welding Boss, Non-Diametrical, Mid-Radius

    The oblique center line should be marked on the side of the true center line that is closer to the second nozzle location. One end of the oblique line should stop at the horizontal line. Model T17 Installation Guide...
  • Page 39 56 in. (1400 mm) 56.00 in. 0.490 in. (12.44 mm) 60 in. (1500 mm) 60.00 in. 0.489 in. (12.42 mm) 64 in. (1600 mm) 64.00 in. 0.488 in. (12.41 mm) 66 in. 66.00 in. 0.488 in. (12.40 mm) Model T17 Installation Guide...
  • Page 40 Check the boss alignment, then tack weld the carbon steel boss to the pipe in each of the four grooves between the boss scribe marks. Remove the clamp and check the alignment again. If the boss is misaligned by 0.02 in. (0.5 mm) or more, remove the boss, grind off the welds and reinstall it. Model T17 Installation Guide...

  • Page 41: Installing The First Nozzle, Non-Diametrical Mid Radius

    Slide the nozzle over the threaded rod, and align the contoured end of the nozzle so that it matches the pipe arc. Then slide the jig over the threaded rod, fitting the jig into the welding boss. Model T17 Installation Guide...
  • Page 42 Allow the welds to cool for 30 seconds between tacks. Proceed to complete the root pass and subsequent filler passes as required. Allow the welds to cool, then remove the threaded rod, washer, nut, and jig. Model T17 Installation Guide...

  • Page 43: Installing The Second Welding Boss And Nozzle, Non-Diametrical Mid Radius

    Installing the Second Welding Boss and Nozzle, Non-Diametrical Mid Radius Install the second welding boss and nozzle at the required position as described in Installing the First Welding Boss and Installing the First Nozzle. The completed installation should appear as shown below. Model T17 Installation Guide...

  • Page 44: Hot Tapping The Pipe

    The procedure for cold tapping a pipe is the same as the hot tapping procedure. However, an isolation valve is not necessary during the process. The hot tapping medium can be applied directly to the nozzle. Isolation valves will be added after the tapping is complete. Model T17 Installation Guide...

  • Page 45: Chapter 3. Installing An Isolation Valve

    3 INCH 150 LB, RF WELDING NECK FLANGE 2 PLACES; REF ONLY 3 INCH SCH 80 PIPE NOZZLE 2 PLACES; REF ONLY FLOW GASKET DOWNSTREAM TRANSDUCER PORT Figure 6: Installation of Isolation Valves - Standard Assembly Model T17 Installation Guide...
  • Page 46 Chapter 3. Installing an Isolation Valve Model T17 Installation Guide...

  • Page 47: Chapter 4. Inserting T17 Transducers Into The Pipe

    Introduction The T17 transducer is typically installed into a meter body. The meter body is a section of pipe that contains the ports where the transducers will be mounted. The meter body may be prefabricated or created by installing ports on the existing pipe.

  • Page 48: Mounting The Insertion Mechanism

    Chapter 4. Inserting T17 Transducers into the Pipe 4.2.2 Mounting the Insertion Mechanism Before mounting the mechanism on the isolation valve, refer to Figure 7 below to familiarize yourself with its components: • junction box • barrel • packing gland •...
  • Page 49 Chapter 4. Inserting T17 Transducers into the Pipe 4.2.2 Mounting the Insertion Mechanism (cont.)  Visually inspect the transducer to make sure the top Swagelok fitting is not loose.  IMPORTANT: The stop ring at the end of the barrel is supposed to be loose. DO NOT tighten the Swagelok fitting or you could change the transducer alignment.
  • Page 50 Chapter 4. Inserting T17 Transducers into the Pipe 4.2.2 Mounting the Insertion Mechanism (cont.) Retract the barrel from the packing gland so that the transducer head is recessed in the packing gland. You will hear the stop ring click when the transducer is fully recessed.
  • Page 51 Chapter 4. Inserting T17 Transducers into the Pipe 4.2.2 Mounting the Insertion Mechanism (cont.) Lift the gasket and insert the packing tool into the packing nut. Turning the packing tool clockwise, tighten the packing material so that the barrel stays up without support.
  • Page 52 Chapter 4. Inserting T17 Transducers into the Pipe 4.2.2 Mounting the Insertion Mechanism (cont.) Identify the upstream and downstream transducer assemblies. For Standard Velocity Range applications, the upstream and downstream nozzle designations are interchangeable. The system is bi-directional. For Extended Velocity Range applications, the system is not bi-directional. Note which valve is designated upstream and downstream on the pipe.
  • Page 53 Chapter 4. Inserting T17 Transducers into the Pipe 4.2.2 Mounting the Insertion Mechanism (cont.) 10. Lift the insertion mechanism by the barrel and place the insertion mechanism on the isolation valve. 11. Line up the flange holes and bolt the packing gland to the isolation valve.
  • Page 54 Chapter 4. Inserting T17 Transducers into the Pipe 4.2.2 Mounting the Insertion Mechanism (cont.) 12. Using the packing tool, tighten the packing nut again until the nut is recessed. WARNING! The packing material must be securely packed before the isolation valve is opened.

  • Page 55: Aligning The Downstream Transducer For Extended Range Installations

    Chapter 4. Inserting T17 Transducers into the Pipe 4.2.3 Aligning the Downstream Transducer for Extended Range Installations For extended velocity range applications, the head of the downstream transducer is angled at 6° so that it points upstream (into the flow) by 6°. This allows the ultrasonic signal to be pushed into alignment at very high flow rates. At low flow rates, the beam is wide enough to tolerate the initial 6°...
  • Page 56 Chapter 4. Inserting T17 Transducers into the Pipe 4.2.3 Aligning the Downstream Transducer (cont.) The primary method for ensuring that the angled transducer head is pointing in the correct direction uses the alignment marks on the downstream nozzle and the downstream Barrel assembly (see the figure below). The alignment marking on the flange at the top of the Barrel must be in alignment with the nozzle, such that the marking falls between the bolt holes straddling the upstream to downstream centerline, as shown below.
  • Page 57 Chapter 4. Inserting T17 Transducers into the Pipe 4.2.3 Aligning the Downstream Transducer (cont.) Before proceeding, verify that the valve and insertion mechanism are fully bolted in place. Each stud should extend far enough beyond its nut to allow the alignment tool to rest on the stud. Fit the alignment fixture over the nozzle studs so that the two studs straddling the centerline on the nozzle are inserted into the holes on the fixture of the corresponding flange size and rating (3”, 150# or 300#).
  • Page 58 Chapter 4. Inserting T17 Transducers into the Pipe 4.2.3 Aligning the Downstream Transducer (cont.) Place the alignment fixture over the two studs in the flange at the top of the barrel assembly, and rotate the barrel flange until the bubble aligns between the tick marks on the vial. Slowly press the flange toward the insertion mechanism flange until the gasket and raised faces of both flanges are mated.

  • Page 59: Connecting An Xamp

    Chapter 4. Inserting T17 Transducers into the Pipe Connecting an XAMP This section explains how to correctly install and assemble an XAMP into a transducer junction box. Although one type of junction box is used as an example in the steps below, the procedure applies to all three possible junction box options (refer to drawing #752-063, Figure 16 on page 51).
  • Page 60 Chapter 4. Inserting T17 Transducers into the Pipe Connecting an XAMP (cont.) With the transducer and the cable gland assembled, the junction box should now look like Figure 10 below: Figure 10: Assembled Transducer and Cable Gland First, connect the right-angle male BNC plug to the exposed BNC cable from the cable gland assembly, as shown in Figure 11 below.
  • Page 61 Chapter 4. Inserting T17 Transducers into the Pipe Connecting an XAMP (cont.) Connect the female BNC plug of the XAMP to the male BNC transducer head, as shown in Figure 12 below: Figure 12: Female Plug to Male BNC Head Wrap the extra length of cable around the perimeter of the junction box such that the BNC heads do not rest on other cables or on each other.
  • Page 62 Chapter 4. Inserting T17 Transducers into the Pipe Connecting an XAMP (cont.) Place the XAMP body into the junction box (see Figure 14 below), resting the puck gently on the cables below it. Ensure that the cables of the XAMP rest naturally according to the slant at which they exit the epoxy, to reduce stress and strain on the joint.
  • Page 63 Chapter 4. Inserting T17 Transducers into the Pipe Connecting an XAMP (cont.) Figure 16: Transducer General Arrangement (dwg. #752-063, rev. L) Model T17 Installation Guide...
  • Page 64 Chapter 4. Inserting T17 Transducers into the Pipe Model T17 Installation Guide...

  • Page 65: Chapter 5. Maintaining The T17 Transducers

    Chapter 5. Maintaining the T17 Transducers Removing Transducers After the transducers are properly installed into the pipe nozzles as described in Chapter 4.“Inserting T17 Transducers into the Pipe”, the T17 transducers require no additional adjustments. Periodic inspection of the installation to verify the torque on the mounting bolts may be required, if erratic flow rate measurements are observed.
  • Page 66 Chapter 5. Maintaining the T17 Transducers 5.1.1 Using the Insertion Mechanism (cont.) On the insertion mechanism, remove the bolts that fasten the barrel flange to the packing gland flange. Retract the barrel from the packing gland until the transducer head is recessed in the packing gland. The stop ring will “click”...
  • Page 67 Chapter 5. Maintaining the T17 Transducers 5.1.1 Using the Insertion Mechanism (cont.) CLOSE THE ISOLATION VALVE! WARNING! Make sure the isolation valve is closed before performing the following steps. After closing the isolation valve, remove the bolts that fasten the packing gland flange to the isolation valve flange, and lift the insertion mechanism by the barrel to remove it from the isolation valve.
  • Page 68 Chapter 5. Maintaining the T17 Transducers 5.1.1 Using the Insertion Mechanism (cont.) Install a new flange gasket on the isolation valve. Then, fasten a “blind” flange onto the isolation valve with the bolts removed in the previous step. Disconnect the junction box on the end of the transducer by loosening the compression fitting.

  • Page 69: Chapter 6. Specifications

    Chapter 6. Specifications Chapter 6. Specifications T17 Transducer Physical Specifications Hazardous Area applications, Flare Gas, Hydrocarbon Gases using Applications: Panametrics ultrasonic flow meter Models GF868 and XGF868i Installation Type: Wetted Standard: Titanium   Materials of Construction: Optional: 316 Stainless Steel, Monel...
  • Page 70 Chapter 6. Specifications Model T17 Installation Guide...
  • Page 71 RETURN AUTHORIZATION NUMBER (RAN), and shipping instructions for the return of the instrument to a service center will be provided. If Panametrics Sensing instructs you to send your instrument to a service center, it must be shipped prepaid to the authorized repair station indicated in the shipping instructions.
  • Page 72 Warranty [no content intended for this page] Model T17 Installation Guide...
  • Page 73 Billerica, MA 01821 declare under our sole responsibility that the Models T3, T5, T8, T11, T14 and T17 Wetted Ultrasonic Flow Transducers Series BWT1 / F...PA / XAMP... Ultrasonic Flowmeter Transducer Assembly to which this declaration relates, are in conformity with the following standards: •...
  • Page 74 Model T17 Installation Guide...
  • Page 76 Customer Support Centers U.S.A. The Boston Center 1100 Technology Park Drive Billerica, MA 01821 U.S.A. Tel: 800 833 9438 (toll-free) 978 437 1000 E-mail: mstechsupport@bakerhughes.com Ireland Sensing House Shannon Free Zone East Shannon, County Clare Ireland Tel: +353 61 61470291 E-mail: mstechsupport@bakerhughes.com Copyright 2021 Baker Hughes company.
