Panametrics C-RL Instruction Manual page 54

Chapter
• The prospective short circuit current (PSCC) will not exceed 20mA. No power is dissipated internally when there is
a short circuit.
• The connecting cable shall be secured close to the enclosure to prevent loosening and twisting.
• The mounting hardware shall not contain more than 7.5% Magnesium, Titanium or Zirconium.
• The assembly shall not be insulated beyond the plastic-to-metal joint on the transducer body. The assembly
shall not be mounted on the top surface of a pipe or duct.
EU / EEA Installation Compliance
The use of this apparatus is subject to the EU directive on minimum requirements for improving the safety and health
protection of workers potentially at risk from explosive atmospheres, Council Directive 1999/92/EC. The installer is
required to be familiar with this document or the National transposing legislation.
C-Rx Transducer Assembly Details
Manufacturer and certificate owner:
Alternative manufacturing site:
QAN License Number:
Notified Body for Quality Assurance:
Notified Body Number:
Certificate Number:
Apparatus Markings (see example below): II 2 G Ex d mb IIC T6 Gb; II 2 D Ex mb tb IIIC T80°C Db
Ambient temperature range (ATEX):
Pipe surface temperature range (ATEX):
The manufacturing date is encoded in the transducer's serial number; The serial number format (see label below) is:
MMYYNNNN, where MMYY is the month and year of construction and NNNN is a sequential number.
2
Panametrics Infrastructure Sensing Inc., Billerica, MA 01821, USA.
Panametrics EMEA, Shannon, Co. Clare, Ireland
0794 (USA) or 0795 (Ireland)
SGS Baseefa
1180
KEMA 02ATEX2337 X
-40°C to +75°C
-40°C to +75°C
