ADVANCED ADVANCED 2
FUNCTION
CHANNEL
FLASH DIMMER
1
Strobe dimmer
FLASH STROBE
No flash/Closed
Strobe slow to fast
2
Open
Random strobe slow to fast
Open
BG DIMMER
3
Strobe dimmer
BG STROBE
No flash/Closed
Strobe slow to fast
4
Open
Random strobe slow to fast
Open
AUTO FX
No Function
FX 1
FX 2
FX 3
FX 4
FX 5
FX 6
FX 7
FX 8
FX 9
FX 10
FX 11
5
FX 12
FX 13
FX 14
FX 15
FX 16
FX 17
FX 18
FX 19
FX 20
FX 21
FX 22
RESERVED (TBD)
Random pixel (with density)
FX SPEED
6 Static indexing
From slow to fast
DIMMER
From MENU
Mode OFF
7
Mode 1
Mode 2
Mode 3
SUNBLAST3500MAX
DMX
Value
000 - 255
000 - 030
031 - 100
101 - 130
131 - 200
201- 255
000 - 255
000 - 030
031 - 100
101 - 130
131 - 200
201- 255
000 - 010
011 - 015
016 - 020
021 - 025
026 - 030
031 - 035
036 - 040
041 - 045
046 - 050
051 - 060
061 - 065
066 - 070
071 - 075
076 - 080
081 - 085
086 - 090
091 - 095
096 - 100
101 - 105
106 - 110
111 - 115
116 - 120
121 - 125
126 - 205
206 - 255
000 - 050
051 - 255
000 - 051
052 - 101
102 - 152
153 - 203
204 - 255
ADVANCED ADVANCED 2
FUNCTION
CHANNEL
PIXEL 1 WHITE
8
0~100%
PIXEL 2 WHITE
9
0~100%
PIXEL 2 WHITE
10
0~100%
PIXEL 4 WHITE
11
0~100%
... ......
PIXEL 45 WHITE
52
0~100%
PIXEL 46 WHITE
53
0~100%
PIXEL 47 WHITE
54
0~100%
PIXEL 48 WHITE
55
0~100%
DMX
Value
000 - 255
000 - 255
000 - 255
000 - 255
...
000 - 255
000 - 255
000 - 255
000 - 255
