3
Reset
WPS/Reset port
The images below show the dimensions for the camera. The measurements are in millimeters (mm):
3 Connection & Installation
This section provides information about the connection and installation of Amcrest POE Bullet Cameras.
3.1 Connection Guide
The camera initially should be connected via the following method:
In addition to connecting the camera to a computer, the camera can also be connected to a power source, by
connecting the power cable to both a power outlet, and the camera.
Touching the ends of the wire together for more than 5 seconds
Power
resets the device to factory default settings.
8
