Main features

3 Main features
EVAL-M1-099M is a control evaluation board for motor control application. The kit demonstrates Infineon's
motion control IC technology.
Main features of Motion Control IC are:
• MCE (Motion Control Engine) - Dedicated computation engine for high efficiency sinusoidal sensorless
motor control
• Supports both interior and surface permanent magnet motor
• Built-in hardware for single or leg shunt current feedback reconstruction
• Loss minimization Space Vector PWM
• Two-channel analog output
• JTAG programming port for emulation/ debugger
• Serial communication interface (UART)
• Internal 16 Kbyte OTP memory
• Multiple motor parameter support
• 3.3V single power supply
• V control mode
SP
• PG output
• Internal temperature sensing
• External NTC thermistor from power board temperature sensing support.
The evaluation board characteristics are:
• Complete kit for running any permanent magnet motor via sensorless sinusoidal control
• 3.3V single power supply
• JTAG and UART interface, isolated via opto-isolation box
• Capable of 3-phase and three types of 2-phase modulation
• RoHS complaint
• PCB is 45 x 45 mm and has two layers with 35 μm copper each
