EVAL-M1-099M-C User Manual
iMOTION™ Modular Application Design Kit
Main features
Parameters
DC Bus sensing range
Current feedback
Current sensing device
Current Op-amp Configuration
Current Op-amp Gain
Resolution
Latency
Protections
Internal current trip level
On board power supply
1.8V
PCB characteristics
Material
Dimension
System environment
Ambient temperature
Application Note
Values
494.0V max
50mV – 1100mV
Non-Inverting
1.302
12-bit
1 pwm cycle
1.2V Average
1.8V+/-5%
FR4, 1.6MM thickness
Copper thickness = 1oz (35um)
45mmx45mm
0-70°C
7
Conditions / comments
Single shunt resistor
Leg shunt resistor
PCB design may reduce the
resolution
From IC for ADC reference
95%RH Max (Non-Condensing)
<Revision 1.0>
<2017-08-21>
