Pin assignments
Pin Name
VTH
15
IV+
16
IV-
17
IW+
18
IW-
19
20 VCC
Table 6 and Table 7 include the details of test signal pin connectors.
Table 6 Test signals pin
Pin Name
1 GND
2 1.8V
VSP
3
4 VTH
AIN3
5
IFBVO
6
Table 7 Test signals pin
Pin Name
1 GK
GPIO1
2
3 DIR
4 GPIO3
5 DIN
6 PG
GND
7
8 +3.3V
Application Note
Pin Name Connectors
Thermistor input
Shunt voltage phase V
Ground
Shunt voltage phase W
Ground
Defined for 15 V Power Supply (not used in this board)
Pin Name Connectors
Ground
On board 1.8V supply
Input, Analog input channel 0 (0 – 1.25 V), also used for Standby Mode wake-
up
Input, Voltage input of external temperature sense
Input, Analog input channel 3 (0 – 1.25 V), needs to be pulled down to VSS if
unused
Operational amplifier output for 2nd leg shunt resistor current sensing
Pin Name Connector
Output, Gatekill
Test IO pin
Input, motor direction select
Input, User mode select
Input, for Frequency control function
Output, Pulse generate
Ground
+3.3 V power supply
