Digital Interface

Socket strip connector J6 provides the digital I/O connections between the ADS8350EVM board and the
simple capture card board.
Table 3 summarizes the pinout for connector J6.
Terminal Number
J6.2, J6.10, J6.15, J6.16,
J6.18
J6.4
J6.11, J6.12
J6.13
J6.34
J6.36
J6.40
J6.42
3.1 Serial Peripheral Interface (SPI)
The ADS8350 digital output is available in SPI-compatible format, which makes interfacing with
microprocessors, digital signal processors (DSPs), and FPGAs easy. The ADS8350EVM offers 47-Ω
resistors between the SPI signals and connector J6 to aid with signal integrity. Typically, in high-speed
SPI communication, fast signal edges can cause overshoot; these 47-Ω resistors slow down the signal
edges in order to minimize signal overshoot.
2
3.2 I C Bus for Onboard EEPROM
The ADS8350EVM has an I
name and assembly date. It is not used in any form by the ADS8350 converter.
SBAU218A – April 2014 – Revised October 2014
Submit Documentation Feedback
Table 3. Connector J6 Pinout
Signal
GND Ground connections
EVM PRESENT EVM present, active low
2
I C bus; used only used to program the U7
2
I C™ bus
EEPROM on the EVM board
3.3-V digital supply from simple capture card
DVDD
controller board
CS Chip select, active low
SCLK Serial interface clock
SDO_A Serial data output for channel A
SDO_B Serial data output for channel B
2
C bus to communicate with the onboard EEPROM that records the board
