APPENDIX D: PRODUCT SPECIFICATIONS

Environmental Specifications

Operating Temperature
Storage Temperature
Relative Humidity
Pollution Degree
Vibration
Sinusoidal
Random
Impact Shock
Isolation, Inputs to Controller
Corrosion Protection
Electric Noise Immunity
Conducted Noise
Radiated Noise
Electrostatic Discharge
78
0 to 60 C (32 to 140 F)
-40 to 70C (-40 to 158 F)
5% to 95% non-condensing
2, IEC 664, 664A
IEC 68-2-6 Test Fc
0.15 peak to peak, 10 – 57 Hz
1.0g. 57 – 150 Hz
IEC 68-2-34 or NAVMAT p-9492
2
Test Fdc with 0.04 g /Hz, 80 – 350 Hz and
3db/Octave roll off, 80 -20 Hz and
350 – 2000Hz at 10 min/Axis
IEC 68-2-27, Test Ea. Half Sine 15g, 11ms
1500 VRMS except where specified
All parts of corrosion resistant material or plated/painted as corrosion
protection
IEC 801 Part 4 Level 3
MIL-STD-461B, Part 4:CS01, CS02, CS06
IEC 255-4, Appendix C
IEC 4517/79 Com(78) 766 Final, Part 4
IEC 472, 2.5 KV
IEC 801 Part 3, Level 3
MIL-STD-461B, Part 4 RS01, RS02
IEC 801. Part 2, Level 4 (15kV)
