CTI 2500 Series Quick Start Manual

Hide thumbs Also See for 2500 Series:
Table of Contents

Advertisement

Quick Links

Download this manual
Control Technology Inc.
QUICK START MANUAL
Version 1.7
Powered by zenon
2500-VPxx Quick Start Manual V1.7

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2500 Series and is the answer not in the manual?

Questions and answers

Related Manuals for CTI 2500 Series

Summary of Contents for CTI 2500 Series

  • Page 1 Control Technology Inc. QUICK START MANUAL Version 1.7 Powered by zenon 2500-VPxx Quick Start Manual V1.7...
  • Page 2 Every effort has been made to ensure the accuracy of this document; however, errors do occasionally occur. CTI provides this document on an “as is” basis and assumes no responsibility for direct or consequential damages resulting from the use of this document.
  • Page 3 PREFACE This Quick Start Manual provides reference information for the CTI 2500 Series Visualization Panels. The information in this manual is directed to individuals who will be installing and operating the panel as well as those who will be designing systems that use the panel.
  • Page 4 Notes alert the user to special features or procedures. CAUTION Cautions alert the user to procedures that could damage equipment. WARNING Warnings alert the user to procedures that could damage equipment and endanger the user. CTI 2500-VPxx Quick Start Manual V1.7...

  • Page 5: Table Of Contents

    3.4.1 Setting Properties Window Format 3.4.2 Adding a PLC Driver to the Project 3.4.3 Configuring zenon Runtime Graphical Settings 3.5 Starting a New Project Using the CTI Project Template ........29 3.6 Building a Project with the zenon Editor ..............33 3.6.1 Adding Frames and Screens 3.6.1.1 Adding a Frame...
  • Page 6 3.7.1 Configuring Communications Between Editor PC and HMI Panel 62 3.7.2 Configuring and Establishing a Remote Transfer Connection 3.7.1 Transferring Project Files and Setting Start Project 3.8 Running Your Project for the First Time..............68 LIMITED PRODUCT WARRANTY .................69 REPAIR POLICY ....................71 CTI 2500-VPxx Quick Start Manual V1.7...

  • Page 7: Chapter 1 Hardware Overview And Installation

    CHAPTER 1 HARDWARE OVERVIEW AND INSTALLATION 1.1 Introduction The CTI 2500-VPxx Visualization Panel is a color, touchscreen HMI (Human Machine Interface) panel, available in 15” or 12” sizes. It is especially suitable for process control applications that require advanced graphical...

  • Page 8: Io Connections Diagram

    1.2.2 IO Connections Diagram CTI 2500-VP15xx Quick Start Manual V1.7...
