CHAPTER 8
The product embedded web server displays information about the operation of the Janus controller and provides a
means to configure product operation. The web pages are described in the following sections.

8.1 Product Information

This page provides information about the controller
Product Number
Product Name
Serial Number
Manufacture Date
Module Identifier: Assigned by user in General Settings page
Hardware Configuration: Designator that allows software to determine hardware compatibility
Firmware Version
Firmware Date
FPGA Version
Build Information 1 & 2: ( CTI development and support information)
Clock Synchronization Mode: Determines how the controller clock is set)
Startup Mode: Determines how the controller starts up when reset or powered up
Front Panel SD Card Status: If inserted, displays Utilization Percentage
DNS (Domain Name Service) Address Method (Auto/Manual)
Primary DNS Server IP Address
Secondary DNS Server IP Address
Domain suffix
HTTPS Basic Authentication Enabled: Authentication for webserver access
HTTPS Encryption Enabled: Encryption of web server traffic
Ethernet MAC Address
Internal Switch Mode
CPU Temperature (° C)
Dipswitch Settings
User Jumper Selections
Network Settings: For Primary and Alternate subnets
CTI Janus Programmable Automation Controller IOG

EMBEDDED WEB SERVER

51
