Event message #5
Event message #6
Event message #7
Event message #8
Event message #9
Event message #10
Event message #11
Event message #12
Event message #13
Event message #14
Event message #15
Kiss-off message
Address message
Programming the control panel
Format (protocol)
The format used for voice reporting with the NX-535N is format 16.
This is programmed in the control panel on location 2 (for phone #1)
Assigning messages to alarm events
Once you have configured the phone and recorded the messages into the NX-
535N, you need to assign each event you want to report to a recorded message.
Each event can have one of the 15 pre-recorded voice messages assigned to it.
The control panel has a communicator code for each event. Having a record of
your voice messages is useful here.
Assigning messages to a zone configuration group
Assigning messages to a zone configuration group will be done in the location for
the "ALARM EVENT CODES FOR THE CONFIGURATION GROUPS". These
locations start at location 110 (for zone configuration group 1) till location 168 (for
zone configuration group 30). In these locations you just have to fill in a value
between 1 and 15, which means selecting 1 of the 15 messages you have pre-
recorded.
NX-535N Voice Module Installation Manual
Idem Event message #1
Idem Event message #1
Idem Event message #1
Idem Event message #1
Idem Event message #1
Idem Event message #1
Idem Event message #1
Idem Event message #1
Idem Event message #1
Idem Event message #1
Idem Event message #1
Played back after sending kiss-off by means of
DTMF code
Played back together with event message
8.5 sec
8.5 sec
8.5 sec
8.5 sec
8.5 sec
8.5 sec
8.5 sec
8.5 sec
8.5 sec
8.5 sec
8.5 sec
10 sec
20 sec
11
