NX-535N-V3 Voice Module
Installation Manual
P/N 1077954 • REV 1.01 • ISS 24FEB12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Interlogix NX-535N-V3 and is the answer not in the manual?

Questions and answers

Summary of Contents for UTC Fire and Security Interlogix NX-535N-V3

  • Page 1 NX-535N-V3 Voice Module Installation Manual P/N 1077954 • REV 1.01 • ISS 24FEB12...
  • Page 2 Copyright © 2011 UTC Fire & Security. All rights reserved. Trademarks and Interlogix, NX-535N-V3 and logo are trademarks of UTC Fire & Security. patents Other trade names used in this document may be trademarks or registered trademarks of the manufacturers or vendors of the respective products. Manufacturer UTC Fire &...
  • Page 3: Table Of Contents

    Content Overview 2 Installing the NX-535N-V3 voice module 3 Programming the NX-535N-V3 voice module with a menu 4 Configuring the control panel for voice reporting 4 Recording voice messages 5 Playing back messages 5 Configuring handshake and kiss off 6 Glossary 6 Programming the locations for the NX-535N-V3 8 Recording / Playing back messages 8...
  • Page 4: Overview

    Overview The NX-535N-V3 voice module reports alarm events to designated phone numbers using pre-recorded voice messages. You record the voice messages using a normal analog telephone. When an alarm event occurs, the control panel establishes a telephone connection with a specified phone number and informs the NX-535N-V3 voice module to report configured events.
  • Page 5: Installing The Nx-535N-V3 Voice Module

    Installing the NX-535N-V3 voice module The NX-535N-V3 voice module must be installed in the upper left corner from the main panel. If a NX-7002N-V3 GSM module is used then the voice module must be installed on top of the GSM module by using the short spacers and the tie rip. Make sure that the tie rip hole and the small holes are used (see Figure 1).
  • Page 6: Programming The Nx-535N-V3 Voice Module With A Menu

    Programming the NX-535N-V3 voice module with a menu Figure 2. NX-535N-V3 menu structure Recording Leader Message 11.1 11.1.1 Single Event Message Message 1 11.1.3 11.1.3.1 Messages 2 - 15 Same as above 11.1.5 Address Message 11.1.6 Kiss Off Message Leader Message Playback 11.2.1 11.2...
  • Page 7: Recording Voice Messages

    Recording voice messages The NX-535N-V3 voice module can store up to 18 recorded voice messages. There must be one leader message and one address message. There can be an optional kiss off message. The remaining 15 messages are event messages. The messages can be recorded one at a time.
  • Page 8: Configuring Handshake And Kiss Off

    Configuring handshake and kiss off Handshake and kiss off can be programmed as any key press or as a specific telephone key. The following steps explain how to configure these digits. Note: The voice protocol cannot generate a ‘fail to communicate’ signal. 1.
  • Page 9 11.2.1 Leader Message A menu command that plays back the leader message. 11.2.2 Single Event Message A menu command that plays back a single message. 11.2.3 Address Message A menu command that plays back the address message. 11.2.4 Kiss Off Message A menu command that plays back the kiss off message.
  • Page 10: Programming The Locations For The Nx-535N-V3

    Programming the locations for the NX-535N- Recording / Playing back messages LOCATION 0 – Recording / playback selector (3 segments, numerical data) Segment 1 – Recording / Playback selector Segment 1 contains the selector whether you want to record, playback or cancel the operation.
  • Page 11: Configuring Handshake And Kiss-Off

    Configuring Handshake and Kiss-off LOCATION 1 – Configuring handshake and Kiss-off (2 segments, numerical data) When the NX-535N module reports an event and the call is answered, the system plays the leader message until the call taker acknowledges the call by means of pressing a specific phone key.
  • Page 12: Examples

    Examples Recording leader message 1. Go to program mode of Voice module (Module 77). 2. Select Location 0. • Segment 1 = 1 (= record mode) • Segment 2 = 0 (= leader message) 3. Connect a telephone handset into the RJ11 phone jack connector on NX- 535N-V3 module.
  • Page 13: Message Table And Lenghts

    4. Press the button on the NX-535N-V3 module and record your message through the handset. Example: “1420 North Main Street Gladewater, press any key to continue”(*). 5. Press the button again to stop recording. Your message is automatically played back. Recording kiss-off message 1.
  • Page 14 Event message #5 Idem Event message #1 8.5 sec Event message #6 Idem Event message #1 8.5 sec Event message #7 Idem Event message #1 8.5 sec Event message #8 Idem Event message #1 8.5 sec Event message #9 Idem Event message #1 8.5 sec Event message #10 Idem Event message #1...
  • Page 15: Nx-535N-V3 Programming Worksheets

    NX-535N-V3 programming worksheets (Defaults are in bold italic text) Location Description Default RECORDING / PLAYBACK SETTINGS Segment 1 Cancel operation Recording mode Playback mode Segment 2 Record / playback leader message Record / playback event message 1 Record / playback event message 2 Record / playback event message 3 Record / playback event message 4 Record / playback event message 5...
  • Page 16: Technical Specifications

    Technical specifications Power supply specifications Power supply voltage 13.8 VDC, 5 VDC Consumption – Not in session 20 mA at 13.8 V, 25 mA at 5 V Consumption – 2 way listen-in in session 20 mA at 13.8 V, 50 mA at 5 V General feature specifications PCB size Dimensions (width x height x...
