Bill of Materials, Layout, and Schematic
8.2
PCB Layout
Figure 13
through
NOTE: Board layouts are not to scale. These figures are intended to show how the board is laid out;
they are not intended to be used for manufacturing ADS8339EVM PCBs.
16
ADS8339EVM-PDK
Figure 16
show the PCB layout for the ADS8339EVM.
Figure 13. ADS8339EVM PCB: Top Layer
Figure 14. ADS8339EVM PCB: Ground Layer
